| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_068T05_9000006218_46489cztM0_level2.fits | modeM0/AS1A13_068T05_9000006218_46489cztM0_level2_quad_clean.evt |
| Size (bytes) | 119,943,360 | 29,499,840 |
| Size | 114.4 MB | 28.1 MB |
| Events in quadrant A | 1,669,524 | 190,012 |
| Events in quadrant B | 848,324 | 205,241 |
| Events in quadrant C | 848,933 | 197,629 |
| Events in quadrant D | 943,155 | 180,179 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5998 | 1 |
| B | 0 | 3541 | 1 |
| C | 0 | 3622 | 3 |
| D | 0 | 3906 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 32 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1639 | 97 | 5.918243% |
| B | 1639 | 52 | 3.172666% |
| C | 1638 | 43 | 2.625153% |
| D | 1638 | 50 | 3.052503% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 1639 | 1639 | 2 | 2 | 0.12% | 0.12% |  |
| B | 1639 | 1639 | 3 | 3 | 0.18% | 0.18% |  |
| C | 1638 | 1638 | 22 | 22 | 1.34% | 1.34% |  |
| D | 1638 | 1638 | 23 | 23 | 1.40% | 1.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 896785 | 21170.32 | 199 | 194 | 42.4 |
| A | 13 | 254 | 2872 | 63.23 | 199 | 194 | 42.4 |
| A | 3 | 137 | 2167 | 46.59 | 199 | 194 | 42.4 |
| B | 0 | 190 | 22135 | 521.2 | 203 | 197 | 42.1 |
| B | 5 | 172 | 19194 | 451.33 | 203 | 197 | 42.1 |
| B | 12 | 111 | 5053 | 115.37 | 203 | 197 | 42.1 |
| C | 14 | 254 | 82993 | 1720.03 | 196 | 196 | 48.1 |
| C | 13 | 61 | 1370 | 24.39 | 196 | 196 | 48.1 |
| C | 2 | 14 | 1329 | 23.54 | 196 | 196 | 48.1 |
| D | 13 | 249 | 91559 | 1850.06 | 193 | 187 | 49.4 |
| D | 1 | 52 | 60348 | 1218.11 | 193 | 187 | 49.4 |
| D | 7 | 80 | 15204 | 304.06 | 193 | 187 | 49.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
