| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_068T07_9000006222_46526cztM0_level2.fits | modeM0/AS1A13_068T07_9000006222_46526cztM0_level2_quad_clean.evt |
| Size (bytes) | 266,538,240 | 42,094,080 |
| Size | 254.2 MB | 40.1 MB |
| Events in quadrant A | 3,162,921 | 281,964 |
| Events in quadrant B | 1,907,366 | 289,966 |
| Events in quadrant C | 1,529,970 | 290,899 |
| Events in quadrant D | 3,054,090 | 217,891 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 54 | 0 |
| B | 0 | 54 | 0 |
| C | 0 | 54 | 0 |
| D | 0 | 54 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11473 | 0 |
| B | 0 | 7376 | 0 |
| C | 0 | 6478 | 0 |
| D | 0 | 10899 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2707 | 283 | 10.454378% |
| B | 2707 | 243 | 8.976727% |
| C | 2707 | 52 | 1.920946% |
| D | 2708 | 640 | 23.633678% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2707 | 2707 | 60 | 60 | 2.22% | 2.22% |  |
| B | 2706 | 2706 | 163 | 163 | 6.02% | 6.02% |  |
| C | 2707 | 2707 | 33 | 33 | 1.22% | 1.22% |  |
| D | 2708 | 2708 | 583 | 583 | 21.53% | 21.53% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1477637 | 20761.93 | 329 | 323 | 71.2 |
| A | 9 | 191 | 255163 | 3581.48 | 329 | 323 | 71.2 |
| A | 15 | 174 | 55646 | 777.5 | 329 | 323 | 71.2 |
| B | 15 | 201 | 414893 | 6194.46 | 323 | 311 | 66.9 |
| B | 3 | 112 | 71605 | 1065.24 | 323 | 311 | 66.9 |
| B | 0 | 245 | 49558 | 735.82 | 323 | 311 | 66.9 |
| C | 15 | 158 | 178649 | 2233.76 | 329 | 328 | 79.8 |
| C | 14 | 254 | 27628 | 341.98 | 329 | 328 | 79.8 |
| C | 12 | 249 | 18223 | 224.16 | 329 | 328 | 79.8 |
| D | 1 | 52 | 1554836 | 20223.47 | 295 | 285 | 76.9 |
| D | 4 | 223 | 67391 | 873.0 | 295 | 285 | 76.9 |
| D | 13 | 168 | 62598 | 810.64 | 295 | 285 | 76.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
