| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_091T05_9000006224_46528cztM0_level2.fits | modeM0/AS1A13_091T05_9000006224_46528cztM0_level2_quad_clean.evt |
| Size (bytes) | 538,416,000 | 108,904,320 |
| Size | 513.5 MB | 103.9 MB |
| Events in quadrant A | 8,114,024 | 690,847 |
| Events in quadrant B | 4,269,334 | 725,592 |
| Events in quadrant C | 3,133,670 | 734,535 |
| Events in quadrant D | 3,875,578 | 663,444 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28750 | 2 |
| B | 0 | 17313 | 2 |
| C | 0 | 14376 | 2 |
| D | 0 | 16447 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6932 | 732 | 10.559723% |
| B | 6933 | 387 | 5.581999% |
| C | 6933 | 15 | 0.216357% |
| D | 6933 | 138 | 1.990480% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8702 | 6933 | 562 | 562 | 6.46% | 8.11% |  |
| B | 8703 | 6933 | 252 | 252 | 2.90% | 3.63% |  |
| C | 8703 | 6935 | 4 | 4 | 0.05% | 0.06% |  |
| D | 8703 | 6935 | 111 | 111 | 1.28% | 1.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3349035 | 21270.55 | 752 | 734 | 157.4 |
| A | 13 | 248 | 1397964 | 8876.1 | 752 | 734 | 157.4 |
| A | 9 | 191 | 410787 | 2604.92 | 752 | 734 | 157.4 |
| B | 5 | 32 | 352130 | 2367.83 | 752 | 728 | 148.4 |
| B | 12 | 33 | 332138 | 2233.12 | 752 | 728 | 148.4 |
| B | 5 | 255 | 235274 | 1580.43 | 752 | 728 | 148.4 |
| C | 3 | 233 | 60060 | 324.49 | 766 | 770 | 182.7 |
| C | 14 | 254 | 56378 | 304.34 | 766 | 770 | 182.7 |
| C | 1 | 3 | 15552 | 80.9 | 766 | 770 | 182.7 |
| D | 1 | 47 | 189683 | 988.2 | 757 | 735 | 191.2 |
| D | 13 | 249 | 173809 | 905.18 | 757 | 735 | 191.2 |
| D | 2 | 249 | 135946 | 707.15 | 757 | 735 | 191.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
