| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_092T03_9000006234_46595cztM0_level2.fits | modeM0/AS1A13_092T03_9000006234_46595cztM0_level2_quad_clean.evt |
| Size (bytes) | 280,045,440 | 60,327,360 |
| Size | 267.1 MB | 57.5 MB |
| Events in quadrant A | 3,802,308 | 397,618 |
| Events in quadrant B | 1,873,540 | 411,911 |
| Events in quadrant C | 1,678,142 | 392,561 |
| Events in quadrant D | 2,711,675 | 351,933 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14209 | 0 |
| B | 0 | 8120 | 0 |
| C | 0 | 7881 | 3 |
| D | 0 | 10626 | 5 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 78 | 0 |
| B | 0 | 78 | 0 |
| C | 0 | 78 | 0 |
| D | 0 | 78 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3857 | 66 | 1.711174% |
| B | 3857 | 30 | 0.777807% |
| C | 3856 | 12 | 0.311203% |
| D | 3857 | 151 | 3.914960% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3857 | 3857 | 45 | 45 | 1.17% | 1.17% |  |
| B | 3857 | 3857 | 17 | 17 | 0.44% | 0.44% |  |
| C | 3858 | 3857 | 10 | 10 | 0.26% | 0.26% |  |
| D | 3858 | 3858 | 138 | 138 | 3.58% | 3.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1940581 | 22633.31 | 407 | 400 | 85.7 |
| A | 13 | 248 | 154128 | 1793.32 | 407 | 400 | 85.7 |
| A | 9 | 191 | 88207 | 1024.32 | 407 | 400 | 85.7 |
| B | 15 | 201 | 80897 | 981.47 | 407 | 395 | 82.0 |
| B | 2 | 2 | 49385 | 597.28 | 407 | 395 | 82.0 |
| B | 3 | 112 | 25577 | 307.01 | 407 | 395 | 82.0 |
| C | 14 | 254 | 49166 | 503.94 | 401 | 403 | 96.8 |
| C | 15 | 208 | 22666 | 230.08 | 401 | 403 | 96.8 |
| C | 3 | 233 | 17899 | 180.81 | 401 | 403 | 96.8 |
| D | 1 | 52 | 379634 | 3766.71 | 396 | 383 | 100.7 |
| D | 12 | 233 | 197400 | 1956.77 | 396 | 383 | 100.7 |
| D | 2 | 120 | 131398 | 1301.24 | 396 | 383 | 100.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
