| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_080T02_9000006242_46623cztM0_level2.fits | modeM0/AS1A13_080T02_9000006242_46623cztM0_level2_quad_clean.evt |
| Size (bytes) | 542,436,480 | 137,649,600 |
| Size | 517.3 MB | 131.3 MB |
| Events in quadrant A | 6,729,197 | 933,332 |
| Events in quadrant B | 3,726,398 | 885,315 |
| Events in quadrant C | 3,937,810 | 928,464 |
| Events in quadrant D | 5,093,463 | 890,163 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24691 | 0 |
| B | 0 | 16795 | 0 |
| C | 0 | 17356 | 0 |
| D | 0 | 20398 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7635 | 311 | 4.073346% |
| B | 7635 | 253 | 3.313687% |
| C | 7635 | 187 | 2.449247% |
| D | 7635 | 342 | 4.479371% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7635 | 7635 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7635 | 7635 | 19 | 19 | 0.25% | 0.25% |  |
| C | 7635 | 7635 | 56 | 56 | 0.73% | 0.73% |  |
| D | 7635 | 7635 | 217 | 217 | 2.84% | 2.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3280823 | 18082.03 | 861 | 844 | 181.4 |
| A | 9 | 191 | 53256 | 288.94 | 861 | 844 | 181.4 |
| A | 7 | 3 | 51034 | 276.69 | 861 | 844 | 181.4 |
| B | 5 | 32 | 128795 | 780.27 | 834 | 810 | 164.0 |
| B | 15 | 201 | 105264 | 636.81 | 834 | 810 | 164.0 |
| B | 0 | 189 | 71344 | 430.02 | 834 | 810 | 164.0 |
| C | 9 | 54 | 268461 | 1305.26 | 854 | 857 | 205.0 |
| C | 14 | 254 | 255996 | 1244.46 | 854 | 857 | 205.0 |
| C | 12 | 249 | 56776 | 272.75 | 854 | 857 | 205.0 |
| D | 1 | 52 | 620945 | 2749.73 | 867 | 839 | 225.5 |
| D | 13 | 249 | 549416 | 2432.55 | 867 | 839 | 225.5 |
| D | 15 | 127 | 121987 | 537.2 | 867 | 839 | 225.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
