| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_092T16_9000006250_46676cztM0_level2.fits | modeM0/AS1A13_092T16_9000006250_46676cztM0_level2_quad_clean.evt |
| Size (bytes) | 386,026,560 | 79,683,840 |
| Size | 368.1 MB | 76.0 MB |
| Events in quadrant A | 5,049,507 | 511,454 |
| Events in quadrant B | 3,504,197 | 531,381 |
| Events in quadrant C | 2,198,576 | 541,317 |
| Events in quadrant D | 3,151,501 | 480,986 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18167 | 1 |
| B | 0 | 13807 | 1 |
| C | 0 | 10241 | 1 |
| D | 0 | 12856 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4961 | 312 | 6.289055% |
| B | 4961 | 319 | 6.430155% |
| C | 4961 | 13 | 0.262044% |
| D | 4961 | 150 | 3.023584% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6141 | 4962 | 259 | 259 | 4.22% | 5.22% |  |
| B | 6141 | 4962 | 208 | 208 | 3.39% | 4.19% |  |
| C | 6141 | 4962 | 4 | 4 | 0.07% | 0.08% |  |
| D | 6141 | 4962 | 110 | 110 | 1.79% | 2.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2488366 | 22133.47 | 534 | 524 | 112.4 |
| A | 15 | 235 | 442947 | 3936.08 | 534 | 524 | 112.4 |
| A | 13 | 6 | 14572 | 124.98 | 534 | 524 | 112.4 |
| B | 15 | 201 | 609366 | 5771.83 | 540 | 525 | 105.5 |
| B | 12 | 3 | 353447 | 3345.71 | 540 | 525 | 105.5 |
| B | 4 | 171 | 198457 | 1876.4 | 540 | 525 | 105.5 |
| C | 1 | 241 | 45245 | 351.25 | 539 | 542 | 127.3 |
| C | 12 | 250 | 13626 | 102.81 | 539 | 542 | 127.3 |
| C | 14 | 254 | 10562 | 78.73 | 539 | 542 | 127.3 |
| D | 1 | 52 | 433728 | 3169.23 | 529 | 511 | 136.7 |
| D | 13 | 249 | 209652 | 1529.98 | 529 | 511 | 136.7 |
| D | 12 | 128 | 146913 | 1071.01 | 529 | 511 | 136.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
