| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006256_46712cztM0_level2.fits | modeM0/AS1A13_037T01_9000006256_46712cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,894,210,560 | 395,000,640 |
| Size | 1.8 GB | 376.7 MB |
| Events in quadrant A | 23,250,395 | 2,666,337 |
| Events in quadrant B | 11,980,164 | 2,748,143 |
| Events in quadrant C | 15,692,734 | 2,495,222 |
| Events in quadrant D | 17,250,190 | 2,317,133 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 86333 | 2 |
| B | 0 | 53712 | 2 |
| C | 0 | 65327 | 2 |
| D | 0 | 69481 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 506 | 0 |
| B | 0 | 506 | 0 |
| C | 0 | 506 | 0 |
| D | 0 | 506 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 25188 | 454 | 1.802446% |
| B | 25189 | 217 | 0.861487% |
| C | 25189 | 1509 | 5.990710% |
| D | 25189 | 1428 | 5.669141% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 25873 | 25191 | 20 | 20 | 0.08% | 0.08% |  |
| B | 25874 | 25192 | 19 | 19 | 0.07% | 0.08% |  |
| C | 25874 | 25192 | 1354 | 1354 | 5.23% | 5.37% |  |
| D | 25874 | 25192 | 1201 | 1201 | 4.64% | 4.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 11899245 | 20803.24 | 2761 | 2695 | 571.9 |
| A | 9 | 191 | 573909 | 998.87 | 2761 | 2695 | 571.9 |
| A | 13 | 254 | 45399 | 74.68 | 2761 | 2695 | 571.9 |
| B | 4 | 171 | 507940 | 924.55 | 2766 | 2678 | 546.5 |
| B | 0 | 198 | 232066 | 419.74 | 2766 | 2678 | 546.5 |
| B | 12 | 111 | 70440 | 123.99 | 2766 | 2678 | 546.5 |
| C | 12 | 2 | 4705620 | 7605.49 | 2627 | 2636 | 618.4 |
| C | 14 | 254 | 313717 | 503.07 | 2627 | 2636 | 618.4 |
| C | 3 | 233 | 254942 | 408.02 | 2627 | 2636 | 618.4 |
| D | 13 | 168 | 2712061 | 4051.72 | 2646 | 2562 | 668.7 |
| D | 1 | 52 | 2077527 | 3102.86 | 2646 | 2562 | 668.7 |
| D | 13 | 249 | 1136511 | 1695.68 | 2646 | 2562 | 668.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
