| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T10_9000006272_46822cztM0_level2.fits | modeM0/AS1C07_001T10_9000006272_46822cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,674,240 | 104,984,640 |
| Size | 476.5 MB | 100.1 MB |
| Events in quadrant A | 6,176,888 | 696,950 |
| Events in quadrant B | 4,728,584 | 702,831 |
| Events in quadrant C | 2,923,002 | 720,994 |
| Events in quadrant D | 4,197,301 | 634,189 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22354 | 1 |
| B | 0 | 18246 | 1 |
| C | 0 | 12860 | 1 |
| D | 0 | 16582 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6068 | 250 | 4.119974% |
| B | 6068 | 416 | 6.855636% |
| C | 6068 | 47 | 0.774555% |
| D | 6069 | 328 | 5.404515% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7333 | 6069 | 67 | 67 | 0.91% | 1.10% |  |
| B | 7333 | 6069 | 257 | 257 | 3.50% | 4.23% |  |
| C | 7333 | 6069 | 12 | 12 | 0.16% | 0.20% |  |
| D | 7334 | 6070 | 258 | 258 | 3.52% | 4.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3416275 | 24170.11 | 685 | 671 | 141.3 |
| A | 10 | 255 | 36961 | 256.8 | 685 | 671 | 141.3 |
| A | 9 | 191 | 18460 | 125.88 | 685 | 671 | 141.3 |
| B | 3 | 112 | 1346157 | 10468.99 | 677 | 658 | 128.5 |
| B | 5 | 32 | 343157 | 2664.9 | 677 | 658 | 128.5 |
| B | 15 | 36 | 132980 | 1029.56 | 677 | 658 | 128.5 |
| C | 14 | 254 | 116633 | 717.17 | 695 | 698 | 161.7 |
| C | 3 | 233 | 67372 | 412.44 | 695 | 698 | 161.7 |
| C | 12 | 2 | 11543 | 67.09 | 695 | 698 | 161.7 |
| D | 13 | 249 | 745341 | 4455.76 | 677 | 659 | 167.1 |
| D | 1 | 52 | 232686 | 1388.32 | 677 | 659 | 167.1 |
| D | 12 | 233 | 215146 | 1283.37 | 677 | 659 | 167.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
