| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_053T01_9000006274_46874cztM0_level2.fits | modeM0/AS1A13_053T01_9000006274_46874cztM0_level2_quad_clean.evt |
| Size (bytes) | 990,169,920 | 186,681,600 |
| Size | 944.3 MB | 178.0 MB |
| Events in quadrant A | 11,108,554 | 1,275,048 |
| Events in quadrant B | 6,324,842 | 1,314,025 |
| Events in quadrant C | 6,002,303 | 1,265,333 |
| Events in quadrant D | 12,250,978 | 934,199 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40488 | 17 |
| B | 0 | 27376 | 3 |
| C | 0 | 27192 | 11 |
| D | 0 | 45396 | 29 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 258 | 0 |
| B | 0 | 258 | 0 |
| C | 0 | 258 | 0 |
| D | 0 | 258 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12483 | 261 | 2.090844% |
| B | 12489 | 238 | 1.905677% |
| C | 12485 | 253 | 2.026432% |
| D | 12485 | 2540 | 20.344413% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13365 | 12494 | 1 | 1 | 0.01% | 0.01% |  |
| B | 13365 | 12495 | 64 | 64 | 0.48% | 0.51% |  |
| C | 13366 | 12494 | 134 | 134 | 1.00% | 1.07% |  |
| D | 13366 | 12495 | 2170 | 2170 | 16.24% | 17.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 5813619 | 20837.7 | 1357 | 1325 | 278.9 |
| A | 9 | 191 | 18221 | 60.57 | 1357 | 1325 | 278.9 |
| A | 3 | 137 | 16071 | 52.87 | 1357 | 1325 | 278.9 |
| B | 3 | 112 | 436235 | 1649.04 | 1348 | 1306 | 263.7 |
| B | 5 | 32 | 269132 | 1015.47 | 1348 | 1306 | 263.7 |
| B | 0 | 200 | 111632 | 418.3 | 1348 | 1306 | 263.7 |
| C | 14 | 254 | 643893 | 2038.39 | 1339 | 1342 | 315.2 |
| C | 1 | 241 | 103760 | 324.91 | 1339 | 1342 | 315.2 |
| C | 3 | 233 | 34786 | 106.1 | 1339 | 1342 | 315.2 |
| D | 2 | 249 | 2943332 | 9670.93 | 1232 | 1198 | 304.2 |
| D | 12 | 233 | 2671462 | 8777.28 | 1232 | 1198 | 304.2 |
| D | 13 | 249 | 1174514 | 3856.74 | 1232 | 1198 | 304.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
