| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_053T01_9000006274_46880cztM0_level2.fits | modeM0/AS1A13_053T01_9000006274_46880cztM0_level2_quad_clean.evt |
| Size (bytes) | 510,943,680 | 102,744,000 |
| Size | 487.3 MB | 98.0 MB |
| Events in quadrant A | 6,032,862 | 707,492 |
| Events in quadrant B | 5,312,535 | 673,519 |
| Events in quadrant C | 3,062,815 | 689,360 |
| Events in quadrant D | 4,037,710 | 619,404 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22020 | 1 |
| B | 0 | 19925 | 1 |
| C | 0 | 13396 | 2 |
| D | 0 | 16204 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6029 | 232 | 3.848068% |
| B | 6030 | 695 | 11.525705% |
| C | 6029 | 104 | 1.724996% |
| D | 6029 | 359 | 5.954553% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7249 | 6029 | 50 | 50 | 0.69% | 0.83% |  |
| B | 7250 | 6031 | 467 | 467 | 6.44% | 7.74% |  |
| C | 7249 | 6030 | 80 | 80 | 1.10% | 1.33% |  |
| D | 7249 | 6030 | 258 | 258 | 3.56% | 4.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3171885 | 22069.26 | 699 | 686 | 143.7 |
| A | 13 | 248 | 76938 | 530.66 | 699 | 686 | 143.7 |
| A | 4 | 0 | 54148 | 372.06 | 699 | 686 | 143.7 |
| B | 3 | 112 | 2029501 | 15441.19 | 676 | 659 | 131.4 |
| B | 4 | 171 | 277421 | 2106.39 | 676 | 659 | 131.4 |
| B | 15 | 36 | 169918 | 1288.2 | 676 | 659 | 131.4 |
| C | 14 | 254 | 400797 | 2547.51 | 674 | 678 | 157.1 |
| C | 12 | 2 | 18382 | 112.72 | 674 | 678 | 157.1 |
| C | 0 | 207 | 7852 | 45.68 | 674 | 678 | 157.1 |
| D | 1 | 52 | 636437 | 3810.41 | 669 | 649 | 166.9 |
| D | 13 | 249 | 505164 | 3023.66 | 669 | 649 | 166.9 |
| D | 2 | 249 | 152785 | 911.78 | 669 | 649 | 166.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
