| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T07_9000006290_46962cztM0_level2.fits | modeM0/AS1A13_071T07_9000006290_46962cztM0_level2_quad_clean.evt |
| Size (bytes) | 867,507,840 | 162,832,320 |
| Size | 827.3 MB | 155.3 MB |
| Events in quadrant A | 9,790,886 | 1,092,959 |
| Events in quadrant B | 10,229,699 | 1,038,896 |
| Events in quadrant C | 4,809,825 | 1,082,178 |
| Events in quadrant D | 6,461,819 | 981,228 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 216 | 0 |
| B | 0 | 216 | 0 |
| C | 0 | 216 | 0 |
| D | 0 | 216 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36025 | 2 |
| B | 0 | 37776 | 2 |
| C | 0 | 22271 | 2 |
| D | 0 | 26878 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10609 | 281 | 2.648695% |
| B | 10609 | 1248 | 11.763597% |
| C | 10609 | 139 | 1.310208% |
| D | 10609 | 422 | 3.977755% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 11979 | 10611 | 24 | 24 | 0.20% | 0.23% |  |
| B | 11979 | 10611 | 768 | 768 | 6.41% | 7.24% |  |
| C | 11979 | 10611 | 29 | 29 | 0.24% | 0.27% |  |
| D | 11979 | 10611 | 273 | 273 | 2.28% | 2.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 5243549 | 22121.22 | 1149 | 1124 | 237.0 |
| A | 0 | 243 | 45404 | 186.85 | 1149 | 1124 | 237.0 |
| A | 7 | 3 | 42586 | 174.96 | 1149 | 1124 | 237.0 |
| B | 3 | 112 | 5188613 | 23870.83 | 1112 | 1077 | 217.3 |
| B | 5 | 255 | 438144 | 2011.19 | 1112 | 1077 | 217.3 |
| B | 0 | 190 | 83928 | 381.24 | 1112 | 1077 | 217.3 |
| C | 1 | 3 | 227820 | 853.34 | 1137 | 1139 | 265.6 |
| C | 14 | 254 | 62764 | 231.99 | 1137 | 1139 | 265.6 |
| C | 15 | 208 | 60958 | 225.19 | 1137 | 1139 | 265.6 |
| D | 13 | 249 | 1215018 | 4308.02 | 1125 | 1088 | 281.8 |
| D | 12 | 3 | 210195 | 742.08 | 1125 | 1088 | 281.8 |
| D | 13 | 112 | 193569 | 683.08 | 1125 | 1088 | 281.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
