| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T08_9000006292_46985cztM0_level2.fits | modeM0/AS1A13_071T08_9000006292_46985cztM0_level2_quad_clean.evt |
| Size (bytes) | 664,767,360 | 92,427,840 |
| Size | 634.0 MB | 88.1 MB |
| Events in quadrant A | 6,286,901 | 668,574 |
| Events in quadrant B | 11,347,123 | 394,418 |
| Events in quadrant C | 2,940,853 | 672,988 |
| Events in quadrant D | 3,537,678 | 616,608 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22985 | 3 |
| B | 0 | 38149 | 7 |
| C | 0 | 13634 | 1 |
| D | 0 | 15129 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6385 | 287 | 4.494910% |
| B | 6384 | 3299 | 51.676065% |
| C | 6386 | 65 | 1.017852% |
| D | 6386 | 114 | 1.785155% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7025 | 6386 | 33 | 33 | 0.47% | 0.52% |  |
| B | 7025 | 6386 | 2564 | 2564 | 36.50% | 40.15% |  |
| C | 7026 | 6387 | 50 | 50 | 0.71% | 0.78% |  |
| D | 7026 | 6387 | 96 | 96 | 1.37% | 1.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3340510 | 23251.67 | 690 | 675 | 143.6 |
| A | 14 | 248 | 112645 | 779.52 | 690 | 675 | 143.6 |
| A | 9 | 191 | 71530 | 493.28 | 690 | 675 | 143.6 |
| B | 3 | 112 | 8823505 | 77395.17 | 578 | 562 | 114.0 |
| B | 4 | 171 | 139157 | 1215.76 | 578 | 562 | 114.0 |
| B | 5 | 32 | 41738 | 361.2 | 578 | 562 | 114.0 |
| C | 14 | 254 | 189287 | 1169.9 | 684 | 686 | 161.2 |
| C | 12 | 2 | 73596 | 452.26 | 684 | 686 | 161.2 |
| C | 13 | 61 | 4691 | 24.84 | 684 | 686 | 161.2 |
| D | 1 | 52 | 264390 | 1549.33 | 678 | 656 | 170.2 |
| D | 7 | 96 | 262624 | 1538.95 | 678 | 656 | 170.2 |
| D | 13 | 249 | 169068 | 989.35 | 678 | 656 | 170.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
