| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_006T01_9000006294_47015cztM0_level2.fits | modeM0/AS1C09_006T01_9000006294_47015cztM0_level2_quad_clean.evt |
| Size (bytes) | 239,411,520 | 30,271,680 |
| Size | 228.3 MB | 28.9 MB |
| Events in quadrant A | 2,060,001 | 235,422 |
| Events in quadrant B | 4,247,677 | 85,840 |
| Events in quadrant C | 1,052,690 | 228,908 |
| Events in quadrant D | 1,328,936 | 207,850 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44 | 0 |
| B | 0 | 44 | 0 |
| C | 0 | 44 | 0 |
| D | 0 | 44 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7774 | 0 |
| B | 0 | 14154 | 0 |
| C | 0 | 4768 | 0 |
| D | 0 | 5527 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2197 | 10 | 0.455166% |
| B | 2197 | 1465 | 66.681839% |
| C | 2198 | 18 | 0.818926% |
| D | 2198 | 77 | 3.503185% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2197 | 2197 | 3 | 3 | 0.14% | 0.14% |  |
| B | 2197 | 2197 | 1390 | 1390 | 63.27% | 63.27% |  |
| C | 2198 | 2198 | 16 | 16 | 0.73% | 0.73% |  |
| D | 2198 | 2198 | 67 | 67 | 3.05% | 3.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1122544 | 22656.43 | 229 | 224 | 49.5 |
| A | 13 | 248 | 26365 | 527.71 | 229 | 224 | 49.5 |
| A | 9 | 191 | 10455 | 206.53 | 229 | 224 | 49.5 |
| B | 3 | 112 | 3495070 | 102681.52 | 161 | 156 | 34.0 |
| B | 0 | 200 | 50855 | 1489.55 | 161 | 156 | 34.0 |
| B | 4 | 171 | 33575 | 981.86 | 161 | 156 | 34.0 |
| C | 1 | 3 | 91980 | 1635.51 | 230 | 231 | 56.1 |
| C | 14 | 254 | 58772 | 1043.54 | 230 | 231 | 56.1 |
| C | 8 | 222 | 3593 | 59.93 | 230 | 231 | 56.1 |
| D | 13 | 249 | 142878 | 2427.36 | 228 | 221 | 58.8 |
| D | 1 | 52 | 102233 | 1735.77 | 228 | 221 | 58.8 |
| D | 12 | 233 | 51264 | 868.51 | 228 | 221 | 58.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
