| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_005T01_9000006296_47056cztM0_level2.fits | modeM0/AS1C09_005T01_9000006296_47056cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,791,808,640 | 587,917,440 |
| Size | 2.6 GB | 560.7 MB |
| Events in quadrant A | 35,012,769 | 3,927,067 |
| Events in quadrant B | 26,333,166 | 3,835,182 |
| Events in quadrant C | 16,443,771 | 3,974,249 |
| Events in quadrant D | 22,771,676 | 3,586,303 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 73 | 0 |
| B | 0 | 73 | 0 |
| C | 0 | 73 | 0 |
| D | 0 | 73 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 734 | 0 |
| B | 0 | 734 | 0 |
| C | 0 | 734 | 0 |
| D | 0 | 734 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128119 | 7 |
| B | 0 | 102170 | 9 |
| C | 0 | 75494 | 7 |
| D | 0 | 92596 | 7 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 36083 | 1235 | 3.422664% |
| B | 36082 | 3191 | 8.843745% |
| C | 36083 | 399 | 1.105784% |
| D | 36083 | 1201 | 3.328437% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 43323 | 36090 | 99 | 99 | 0.23% | 0.27% |  |
| B | 43322 | 36089 | 1828 | 1828 | 4.22% | 5.07% |  |
| C | 43323 | 36090 | 105 | 105 | 0.24% | 0.29% |  |
| D | 43323 | 36090 | 753 | 753 | 1.74% | 2.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 18663760 | 22660.4 | 4034 | 3947 | 823.5 |
| A | 13 | 248 | 478683 | 576.52 | 4034 | 3947 | 823.5 |
| A | 9 | 191 | 194763 | 231.73 | 4034 | 3947 | 823.5 |
| B | 3 | 112 | 7983801 | 10716.87 | 3896 | 3778 | 744.6 |
| B | 5 | 172 | 1407076 | 1884.58 | 3896 | 3778 | 744.6 |
| B | 4 | 171 | 564395 | 752.89 | 3896 | 3778 | 744.6 |
| C | 14 | 254 | 466729 | 502.04 | 3997 | 4014 | 921.7 |
| C | 12 | 2 | 266544 | 284.84 | 3997 | 4014 | 921.7 |
| C | 12 | 250 | 78198 | 80.49 | 3997 | 4014 | 921.7 |
| D | 1 | 52 | 4955534 | 5057.77 | 3984 | 3872 | 979.0 |
| D | 13 | 249 | 804614 | 817.9 | 3984 | 3872 | 979.0 |
| D | 14 | 34 | 410538 | 415.38 | 3984 | 3872 | 979.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
