| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_005T01_9000006296_47063cztM0_level2.fits | modeM0/AS1C09_005T01_9000006296_47063cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,417,599,360 | 293,785,920 |
| Size | 1.3 GB | 280.2 MB |
| Events in quadrant A | 17,906,644 | 1,964,404 |
| Events in quadrant B | 12,943,084 | 1,986,513 |
| Events in quadrant C | 8,420,179 | 1,926,096 |
| Events in quadrant D | 11,740,130 | 1,709,904 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 390 | 0 |
| B | 0 | 390 | 0 |
| C | 0 | 390 | 0 |
| D | 0 | 390 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 65277 | 3 |
| B | 0 | 51306 | 3 |
| C | 0 | 39470 | 12 |
| D | 0 | 49001 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18969 | 538 | 2.836206% |
| B | 18969 | 806 | 4.249038% |
| C | 18967 | 170 | 0.896294% |
| D | 18970 | 1079 | 5.687928% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20569 | 18973 | 24 | 24 | 0.12% | 0.13% |  |
| B | 20569 | 18973 | 384 | 384 | 1.87% | 2.02% |  |
| C | 20570 | 18972 | 85 | 85 | 0.41% | 0.45% |  |
| D | 20570 | 18974 | 770 | 770 | 3.74% | 4.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 9670673 | 22561.72 | 2065 | 2018 | 428.5 |
| A | 13 | 248 | 96285 | 219.97 | 2065 | 2018 | 428.5 |
| A | 9 | 191 | 77210 | 175.46 | 2065 | 2018 | 428.5 |
| B | 3 | 112 | 3837639 | 9662.81 | 2046 | 1980 | 397.0 |
| B | 5 | 255 | 393613 | 986.6 | 2046 | 1980 | 397.0 |
| B | 5 | 172 | 116533 | 288.58 | 2046 | 1980 | 397.0 |
| C | 5 | 250 | 264275 | 551.56 | 2037 | 2045 | 475.4 |
| C | 14 | 254 | 141942 | 294.25 | 2037 | 2045 | 475.4 |
| C | 3 | 233 | 39161 | 78.07 | 2037 | 2045 | 475.4 |
| D | 12 | 233 | 1030037 | 2071.14 | 1998 | 1940 | 496.4 |
| D | 2 | 249 | 732284 | 1471.31 | 1998 | 1940 | 496.4 |
| D | 11 | 224 | 668141 | 1342.09 | 1998 | 1940 | 496.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
