| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_003T01_9000006298_47104cztM0_level2.fits | modeM0/AS1C09_003T01_9000006298_47104cztM0_level2_quad_clean.evt |
| Size (bytes) | 563,083,200 | 121,636,800 |
| Size | 537.0 MB | 116.0 MB |
| Events in quadrant A | 7,723,654 | 806,740 |
| Events in quadrant B | 3,887,004 | 827,899 |
| Events in quadrant C | 3,619,021 | 784,733 |
| Events in quadrant D | 5,016,621 | 727,458 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28252 | 3 |
| B | 0 | 16757 | 0 |
| C | 0 | 16459 | 0 |
| D | 0 | 20202 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7704 | 347 | 4.504154% |
| B | 7704 | 191 | 2.479232% |
| C | 7705 | 130 | 1.687216% |
| D | 7705 | 256 | 3.322518% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7704 | 7704 | 6 | 6 | 0.08% | 0.08% |  |
| B | 7704 | 7704 | 8 | 8 | 0.10% | 0.10% |  |
| C | 7705 | 7705 | 39 | 39 | 0.51% | 0.51% |  |
| D | 7705 | 7705 | 173 | 173 | 2.25% | 2.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4267491 | 23645.12 | 867 | 848 | 180.4 |
| A | 7 | 3 | 30321 | 163.34 | 867 | 848 | 180.4 |
| A | 14 | 248 | 28385 | 152.61 | 867 | 848 | 180.4 |
| B | 0 | 190 | 216256 | 1253.83 | 867 | 839 | 171.8 |
| B | 0 | 198 | 54080 | 309.89 | 867 | 839 | 171.8 |
| B | 0 | 200 | 46612 | 266.42 | 867 | 839 | 171.8 |
| C | 0 | 207 | 96187 | 475.83 | 847 | 852 | 200.4 |
| C | 14 | 254 | 85352 | 421.76 | 847 | 852 | 200.4 |
| C | 11 | 16 | 72565 | 357.93 | 847 | 852 | 200.4 |
| D | 2 | 249 | 777396 | 3632.67 | 851 | 821 | 213.8 |
| D | 12 | 3 | 389224 | 1816.88 | 851 | 821 | 213.8 |
| D | 1 | 47 | 232473 | 1083.62 | 851 | 821 | 213.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
