| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_003T01_9000006298_47113cztM0_level2.fits | modeM0/AS1C09_003T01_9000006298_47113cztM0_level2_quad_clean.evt |
| Size (bytes) | 470,626,560 | 109,866,240 |
| Size | 448.8 MB | 104.8 MB |
| Events in quadrant A | 6,760,794 | 736,586 |
| Events in quadrant B | 3,340,995 | 764,215 |
| Events in quadrant C | 2,998,521 | 716,467 |
| Events in quadrant D | 3,817,889 | 656,793 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24660 | 2 |
| B | 0 | 14239 | 2 |
| C | 0 | 13690 | 2 |
| D | 0 | 16104 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6480 | 259 | 3.996914% |
| B | 6481 | 102 | 1.573831% |
| C | 6481 | 68 | 1.049221% |
| D | 6481 | 195 | 3.008795% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7650 | 6481 | 59 | 59 | 0.77% | 0.91% |  |
| B | 7651 | 6482 | 22 | 22 | 0.29% | 0.34% |  |
| C | 7651 | 6482 | 38 | 38 | 0.50% | 0.59% |  |
| D | 7651 | 6482 | 129 | 129 | 1.69% | 1.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3835814 | 25181.54 | 737 | 722 | 152.3 |
| A | 9 | 191 | 51620 | 334.2 | 737 | 722 | 152.3 |
| A | 13 | 254 | 12675 | 78.48 | 737 | 722 | 152.3 |
| B | 8 | 234 | 159894 | 1113.01 | 735 | 713 | 143.0 |
| B | 5 | 32 | 82548 | 572.2 | 735 | 713 | 143.0 |
| B | 4 | 21 | 72598 | 502.63 | 735 | 713 | 143.0 |
| C | 14 | 254 | 195281 | 1189.52 | 707 | 707 | 163.6 |
| C | 11 | 16 | 27730 | 165.2 | 707 | 707 | 163.6 |
| C | 14 | 67 | 6469 | 35.22 | 707 | 707 | 163.6 |
| D | 2 | 249 | 535838 | 3029.9 | 710 | 687 | 176.6 |
| D | 1 | 47 | 184974 | 1043.39 | 710 | 687 | 176.6 |
| D | 12 | 233 | 146071 | 823.13 | 710 | 687 | 176.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
