| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_003T01_9000006298_47121cztM0_level2.fits | modeM0/AS1C09_003T01_9000006298_47121cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,401,338,880 | 294,353,280 |
| Size | 1.3 GB | 280.7 MB |
| Events in quadrant A | 19,715,924 | 1,924,288 |
| Events in quadrant B | 9,830,559 | 2,028,067 |
| Events in quadrant C | 8,889,803 | 1,922,613 |
| Events in quadrant D | 11,962,767 | 1,721,584 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 71246 | 3 |
| B | 0 | 42535 | 3 |
| C | 0 | 40699 | 3 |
| D | 0 | 49264 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 388 | 0 |
| B | 0 | 388 | 0 |
| C | 0 | 388 | 0 |
| D | 0 | 388 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19082 | 1251 | 6.555917% |
| B | 19082 | 333 | 1.745100% |
| C | 19083 | 265 | 1.388671% |
| D | 19082 | 891 | 4.669322% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20542 | 19084 | 634 | 634 | 3.09% | 3.32% |  |
| B | 20542 | 19084 | 50 | 50 | 0.24% | 0.26% |  |
| C | 20543 | 19086 | 86 | 86 | 0.42% | 0.45% |  |
| D | 20542 | 19084 | 592 | 592 | 2.88% | 3.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 10210259 | 23891.49 | 2069 | 2023 | 427.3 |
| A | 0 | 247 | 1226763 | 2866.4 | 2069 | 2023 | 427.3 |
| A | 0 | 226 | 87979 | 201.17 | 2069 | 2023 | 427.3 |
| B | 4 | 21 | 661742 | 1617.69 | 2095 | 2029 | 407.8 |
| B | 0 | 190 | 261468 | 636.17 | 2095 | 2029 | 407.8 |
| B | 5 | 32 | 129840 | 313.41 | 2095 | 2029 | 407.8 |
| C | 14 | 254 | 583197 | 1206.48 | 2056 | 2064 | 481.7 |
| C | 15 | 208 | 101345 | 206.12 | 2056 | 2064 | 481.7 |
| C | 3 | 233 | 66230 | 133.21 | 2056 | 2064 | 481.7 |
| D | 1 | 47 | 1003226 | 1957.67 | 2037 | 1967 | 511.5 |
| D | 2 | 249 | 991413 | 1934.57 | 2037 | 1967 | 511.5 |
| D | 12 | 233 | 642531 | 1252.43 | 2037 | 1967 | 511.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
