| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_019T01_9000006302_47202cztM0_level2.fits | modeM0/AS1A13_019T01_9000006302_47202cztM0_level2_quad_clean.evt |
| Size (bytes) | 603,930,240 | 108,198,720 |
| Size | 576.0 MB | 103.2 MB |
| Events in quadrant A | 10,802,975 | 607,437 |
| Events in quadrant B | 4,123,597 | 759,002 |
| Events in quadrant C | 3,276,821 | 744,693 |
| Events in quadrant D | 3,609,339 | 677,543 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 37122 | 106 |
| B | 0 | 16939 | 61 |
| C | 0 | 14706 | 46 |
| D | 0 | 15613 | 87 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6993 | 1975 | 28.242528% |
| B | 6994 | 398 | 5.690592% |
| C | 6998 | 169 | 2.414976% |
| D | 6995 | 202 | 2.887777% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7725 | 7011 | 1293 | 1293 | 16.74% | 18.44% |  |
| B | 7726 | 7009 | 88 | 88 | 1.14% | 1.26% |  |
| C | 7727 | 7015 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7727 | 7013 | 31 | 31 | 0.40% | 0.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 191 | 4052351 | 25336.14 | 765 | 748 | 159.9 |
| A | 10 | 83 | 3775106 | 23602.43 | 765 | 748 | 159.9 |
| A | 13 | 254 | 13118 | 77.35 | 765 | 748 | 159.9 |
| B | 15 | 201 | 273577 | 1720.54 | 807 | 781 | 158.6 |
| B | 0 | 190 | 193811 | 1217.45 | 807 | 781 | 158.6 |
| B | 5 | 172 | 169125 | 1061.76 | 807 | 781 | 158.6 |
| C | 14 | 254 | 57136 | 296.79 | 805 | 808 | 189.8 |
| C | 15 | 208 | 48227 | 249.85 | 805 | 808 | 189.8 |
| C | 14 | 67 | 14407 | 71.65 | 805 | 808 | 189.8 |
| D | 2 | 249 | 186155 | 920.35 | 805 | 780 | 201.4 |
| D | 5 | 171 | 85212 | 419.19 | 805 | 780 | 201.4 |
| D | 1 | 47 | 49090 | 239.85 | 805 | 780 | 201.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
