| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_025T01_9000006312_47271cztM0_level2.fits | modeM0/AS1A13_025T01_9000006312_47271cztM0_level2_quad_clean.evt |
| Size (bytes) | 509,264,640 | 107,023,680 |
| Size | 485.7 MB | 102.1 MB |
| Events in quadrant A | 7,411,082 | 684,940 |
| Events in quadrant B | 3,534,286 | 759,430 |
| Events in quadrant C | 2,913,129 | 723,324 |
| Events in quadrant D | 4,505,737 | 633,943 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26505 | 131 |
| B | 0 | 14722 | 33 |
| C | 0 | 13048 | 20 |
| D | 0 | 18099 | 81 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6271 | 547 | 8.722692% |
| B | 6285 | 114 | 1.813842% |
| C | 6290 | 11 | 0.174881% |
| D | 6281 | 373 | 5.938545% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7558 | 6299 | 298 | 298 | 3.94% | 4.73% |  |
| B | 7558 | 6299 | 51 | 51 | 0.67% | 0.81% |  |
| C | 7559 | 6298 | 5 | 5 | 0.07% | 0.08% |  |
| D | 7559 | 6299 | 345 | 345 | 4.56% | 5.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3551462 | 24139.6 | 712 | 698 | 147.1 |
| A | 9 | 191 | 1057055 | 7181.56 | 712 | 698 | 147.1 |
| A | 0 | 243 | 16030 | 104.23 | 712 | 698 | 147.1 |
| B | 0 | 200 | 412173 | 2874.65 | 736 | 714 | 143.1 |
| B | 0 | 183 | 62324 | 430.44 | 736 | 714 | 143.1 |
| B | 0 | 190 | 32762 | 223.9 | 736 | 714 | 143.1 |
| C | 14 | 254 | 23643 | 133.69 | 727 | 730 | 171.4 |
| C | 1 | 3 | 20287 | 114.11 | 727 | 730 | 171.4 |
| C | 3 | 233 | 15742 | 87.59 | 727 | 730 | 171.4 |
| D | 6 | 112 | 1317262 | 7341.18 | 710 | 689 | 179.3 |
| D | 12 | 233 | 102586 | 568.18 | 710 | 689 | 179.3 |
| D | 1 | 47 | 80674 | 445.99 | 710 | 689 | 179.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
