| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_053T01_9000006326_47426cztM0_level2.fits | modeM0/AS1A13_053T01_9000006326_47426cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,433,386,880 | 442,370,880 |
| Size | 2.3 GB | 421.9 MB |
| Events in quadrant A | 28,444,580 | 2,965,143 |
| Events in quadrant B | 16,792,050 | 2,989,505 |
| Events in quadrant C | 12,716,691 | 2,991,228 |
| Events in quadrant D | 29,904,384 | 2,467,336 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 105017 | 4 |
| B | 0 | 69626 | 4 |
| C | 0 | 59310 | 5 |
| D | 0 | 109414 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 580 | 0 |
| B | 0 | 580 | 0 |
| C | 0 | 580 | 0 |
| D | 0 | 580 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 28789 | 1016 | 3.529126% |
| B | 28789 | 1469 | 5.102643% |
| C | 28788 | 368 | 1.278310% |
| D | 28789 | 3960 | 13.755254% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 30484 | 28793 | 67 | 67 | 0.22% | 0.23% |  |
| B | 30484 | 28793 | 703 | 703 | 2.31% | 2.44% |  |
| C | 30483 | 28792 | 51 | 51 | 0.17% | 0.18% |  |
| D | 30484 | 28793 | 3533 | 3533 | 11.59% | 12.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 14662054 | 22298.29 | 3168 | 3091 | 657.4 |
| A | 9 | 191 | 1501081 | 2278.65 | 3168 | 3091 | 657.4 |
| A | 14 | 248 | 38505 | 53.87 | 3168 | 3091 | 657.4 |
| B | 5 | 32 | 3111787 | 5104.87 | 3131 | 3027 | 609.0 |
| B | 5 | 255 | 599300 | 979.14 | 3131 | 3027 | 609.0 |
| B | 0 | 198 | 235054 | 381.01 | 3131 | 3027 | 609.0 |
| C | 0 | 207 | 308299 | 414.06 | 3148 | 3155 | 737.0 |
| C | 3 | 233 | 41120 | 51.52 | 3148 | 3155 | 737.0 |
| C | 12 | 249 | 40698 | 50.94 | 3148 | 3155 | 737.0 |
| D | 6 | 112 | 14651844 | 19301.71 | 3029 | 2927 | 758.9 |
| D | 2 | 249 | 1433435 | 1884.87 | 3029 | 2927 | 758.9 |
| D | 12 | 233 | 1081298 | 1420.88 | 3029 | 2927 | 758.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
