Observation information
- date-obs: 2024-07-17
- time-obs: 23:00:54.875600000
- date-end: 2024-07-18
- time-end: 04:46:58.845200000
- obs_id: A13_071T01_9000006340
- exposure: 17503.0517094
- sourceid: ngc3201
- observer: annapurni
- ra_pnt: 154.4034
- dec_pnt: -46.41247
Basic statistics of files
Param |
Original file |
Final file |
Filename | modeM0/AS1A13_071T01_9000006340_47614cztM0_level2.fits
| modeM0/AS1A13_071T01_9000006340_47614cztM0_level2_quad_clean.evt
|
Size (bytes) | 1,520,438,400 | 294,678,720 |
Size | 1.4 GB
| 281.0 MB
|
Events in quadrant A | 22,948,128 | 1,851,243 |
Events in quadrant B | 9,761,189 | 2,067,663 |
Events in quadrant C | 9,049,912 | 1,980,029 |
Events in quadrant D | 13,013,519 | 1,676,870 |
Level1 data integrity
Mode M0 |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 82348 | 3 |
B | 0 | 42072 | 3 |
C | 0 | 41223 | 3 |
D | 0 | 52854 | 3 |
Mode M9 |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 12 | 0 |
B | 0 | 12 | 0 |
C | 0 | 12 | 0 |
D | 0 | 12 | 0 |
Mode SS |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 396 | 0 |
B | 0 | 396 | 0 |
C | 0 | 396 | 0 |
D | 0 | 396 | 0 |
Data saturation
Quadrant | Total seconds | Saturated seconds | Saturation percentage |
---|
A | 19534 | 2214 | 11.334084% |
B | 19535 | 433 | 2.216534% |
C | 19535 | 296 | 1.515229% |
D | 19534 | 1519 | 7.776185% |
Noise dominated fraction
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
Quadrant |
# 1 sec bins |
Bins with >0 counts |
Bins with >2000 counts |
High rate bins dominated by noise |
Noise dominated (total time) |
Noise dominated (detector-on time) |
Marked lightcurve |
A | 20764 | 19539 | 1095 | 1095 | 5.27% | 5.60% | |
B | 20765 | 19540 | 13 | 13 | 0.06% | 0.07% | |
C | 20765 | 19540 | 26 | 26 | 0.13% | 0.13% | |
D | 20764 | 19539 | 1096 | 1096 | 5.28% | 5.61% | |
Top noisy pixels
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
Pixel properties |
Quadrant properties |
Quadrant |
DetID |
PixID |
Counts |
Sigma |
Mean |
Median |
Sigma |
A | 10 | 83 | 9941057 | 22444.07 | 2135 | 2084 | 442.8 |
A | 13 | 248 | 2821772 | 6367.39 | 2135 | 2084 | 442.8 |
A | 9 | 191 | 1716305 | 3871.03 | 2135 | 2084 | 442.8 |
B | 0 | 200 | 500678 | 1144.32 | 2200 | 2127 | 435.7 |
B | 5 | 172 | 155439 | 351.89 | 2200 | 2127 | 435.7 |
B | 0 | 186 | 133006 | 300.4 | 2200 | 2127 | 435.7 |
C | 3 | 233 | 274320 | 531.93 | 2172 | 2179 | 511.6 |
C | 14 | 254 | 202563 | 391.67 | 2172 | 2179 | 511.6 |
C | 1 | 3 | 76774 | 145.8 | 2172 | 2179 | 511.6 |
D | 12 | 2 | 2145896 | 4074.03 | 2097 | 2032 | 526.2 |
D | 2 | 249 | 1315136 | 2495.32 | 2097 | 2032 | 526.2 |
D | 13 | 171 | 636867 | 1206.39 | 2097 | 2032 | 526.2 |
Detector plane histogram (DPH)
Histogram calculated using DETX and DETY for each event in the final _common_clean file
Quadrant A |
|
|
Quadrant B |
Quadrant D |
|
|
Quadrant C |
Count rate plots and images
Plot type |
Count rate plots |
Images |
Comparison with Poisson distribution
Blue bars denote a histogram of data divided into 1 sec bins.
Red curve is a Poisson curve with rate = median count rate of data. |
|
|
Quadrant-wise count rates
Data is divided into 100 sec bins |
|
|
Module-wise count rates for Quadrant A
Data is divided into 100 sec bins |
|
|
Module-wise count rates for Quadrant B
Data is divided into 100 sec bins |
|
|
Module-wise count rates for Quadrant C
Data is divided into 100 sec bins |
|
|
Module-wise count rates for Quadrant D
Data is divided into 100 sec bins |
|
|
Housekeeping plots
Parameter |
Plot |
CZT HV Monitor | |
D_VDD | |
Temperature 1 | |
Veto HV Monitor | |
Veto LLD | |
Alpha Counter | |
_CPM_Rate | |
CZT Counter | |
+2.5 Volts monitor | |
+5 Volts monitor | |
_ROLL_ROT | |
_Roll_DEC | |
_Roll_RA | |
Veto Counter | |
