| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T01_9000006340_47617cztM0_level2.fits | modeM0/AS1A13_071T01_9000006340_47617cztM0_level2_quad_clean.evt |
| Size (bytes) | 510,350,400 | 107,009,280 |
| Size | 486.7 MB | 102.1 MB |
| Events in quadrant A | 8,193,788 | 673,116 |
| Events in quadrant B | 3,238,911 | 742,875 |
| Events in quadrant C | 3,064,669 | 710,035 |
| Events in quadrant D | 3,880,022 | 652,091 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29258 | 3 |
| B | 0 | 14015 | 1 |
| C | 0 | 13742 | 1 |
| D | 0 | 15959 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6628 | 757 | 11.421243% |
| B | 6629 | 70 | 1.055966% |
| C | 6629 | 49 | 0.739176% |
| D | 6629 | 129 | 1.945995% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7623 | 6629 | 415 | 415 | 5.44% | 6.26% |  |
| B | 7624 | 6630 | 14 | 14 | 0.18% | 0.21% |  |
| C | 7624 | 6630 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7624 | 6630 | 67 | 67 | 0.88% | 1.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3576316 | 23416.21 | 732 | 717 | 152.7 |
| A | 13 | 248 | 1067810 | 6988.28 | 732 | 717 | 152.7 |
| A | 9 | 191 | 686244 | 4489.44 | 732 | 717 | 152.7 |
| B | 0 | 200 | 95288 | 627.36 | 751 | 727 | 150.7 |
| B | 5 | 172 | 91660 | 603.29 | 751 | 727 | 150.7 |
| B | 5 | 32 | 67588 | 443.59 | 751 | 727 | 150.7 |
| C | 3 | 233 | 105014 | 596.79 | 745 | 749 | 174.7 |
| C | 14 | 254 | 43483 | 244.6 | 745 | 749 | 174.7 |
| C | 0 | 207 | 11592 | 62.06 | 745 | 749 | 174.7 |
| D | 2 | 165 | 492116 | 2647.68 | 746 | 721 | 185.6 |
| D | 2 | 249 | 320349 | 1722.19 | 746 | 721 | 185.6 |
| D | 13 | 171 | 107234 | 573.9 | 746 | 721 | 185.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
