| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T01_9000006340_47620cztM0_level2.fits | modeM0/AS1A13_071T01_9000006340_47620cztM0_level2_quad_clean.evt |
| Size (bytes) | 473,618,880 | 97,032,960 |
| Size | 451.7 MB | 92.5 MB |
| Events in quadrant A | 7,097,517 | 633,227 |
| Events in quadrant B | 3,150,977 | 676,073 |
| Events in quadrant C | 3,119,170 | 644,487 |
| Events in quadrant D | 3,713,582 | 578,797 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25462 | 1 |
| B | 0 | 13175 | 1 |
| C | 0 | 13527 | 1 |
| D | 0 | 15044 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5802 | 627 | 10.806618% |
| B | 5802 | 211 | 3.636677% |
| C | 5803 | 166 | 2.860589% |
| D | 5802 | 403 | 6.945881% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7007 | 5803 | 310 | 310 | 4.42% | 5.34% |  |
| B | 7007 | 5803 | 53 | 53 | 0.76% | 0.91% |  |
| C | 7008 | 5804 | 119 | 119 | 1.70% | 2.05% |  |
| D | 7007 | 5803 | 255 | 255 | 3.64% | 4.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3226387 | 23602.56 | 658 | 646 | 136.7 |
| A | 9 | 191 | 664251 | 4855.56 | 658 | 646 | 136.7 |
| A | 13 | 248 | 634650 | 4638.97 | 658 | 646 | 136.7 |
| B | 0 | 200 | 362591 | 2810.33 | 664 | 645 | 128.8 |
| B | 5 | 172 | 60826 | 467.28 | 664 | 645 | 128.8 |
| B | 5 | 32 | 46122 | 353.11 | 664 | 645 | 128.8 |
| C | 1 | 3 | 500743 | 3270.86 | 648 | 651 | 152.9 |
| C | 3 | 233 | 85147 | 552.65 | 648 | 651 | 152.9 |
| C | 14 | 254 | 10388 | 63.68 | 648 | 651 | 152.9 |
| D | 12 | 1 | 605731 | 3758.1 | 642 | 619 | 161.0 |
| D | 2 | 249 | 464645 | 2881.88 | 642 | 619 | 161.0 |
| D | 2 | 120 | 44693 | 273.72 | 642 | 619 | 161.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
