| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T01_9000006340_47654cztM0_level2.fits | modeM0/AS1A13_071T01_9000006340_47654cztM0_level2_quad_clean.evt |
| Size (bytes) | 546,367,680 | 122,909,760 |
| Size | 521.1 MB | 117.2 MB |
| Events in quadrant A | 8,084,073 | 816,268 |
| Events in quadrant B | 4,099,236 | 826,960 |
| Events in quadrant C | 3,299,800 | 799,573 |
| Events in quadrant D | 4,141,091 | 739,517 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29842 | 0 |
| B | 0 | 17725 | 0 |
| C | 0 | 15907 | 0 |
| D | 0 | 18009 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7747 | 184 | 2.375113% |
| B | 7748 | 130 | 1.677852% |
| C | 7748 | 6 | 0.077439% |
| D | 7748 | 59 | 0.761487% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7747 | 7747 | 19 | 19 | 0.25% | 0.25% |  |
| B | 7748 | 7748 | 49 | 49 | 0.63% | 0.63% |  |
| C | 7748 | 7748 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7748 | 7748 | 55 | 55 | 0.71% | 0.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4230106 | 23438.76 | 859 | 837 | 180.4 |
| A | 9 | 191 | 505254 | 2795.5 | 859 | 837 | 180.4 |
| A | 13 | 248 | 22081 | 117.74 | 859 | 837 | 180.4 |
| B | 0 | 200 | 374506 | 2193.93 | 852 | 825 | 170.3 |
| B | 5 | 172 | 255380 | 1494.53 | 852 | 825 | 170.3 |
| B | 5 | 255 | 30715 | 175.49 | 852 | 825 | 170.3 |
| C | 14 | 254 | 38726 | 193.4 | 835 | 837 | 195.9 |
| C | 3 | 233 | 6401 | 28.4 | 835 | 837 | 195.9 |
| C | 13 | 61 | 5499 | 23.8 | 835 | 837 | 195.9 |
| D | 14 | 49 | 305394 | 1449.66 | 837 | 808 | 210.1 |
| D | 12 | 2 | 178806 | 847.17 | 837 | 808 | 210.1 |
| D | 12 | 218 | 175035 | 829.22 | 837 | 808 | 210.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
