| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_082T01_9000006342_47697cztM0_level2.fits | modeM0/AS1A13_082T01_9000006342_47697cztM0_level2_quad_clean.evt |
| Size (bytes) | 587,393,280 | 126,360,000 |
| Size | 560.2 MB | 120.5 MB |
| Events in quadrant A | 8,410,388 | 820,854 |
| Events in quadrant B | 3,967,943 | 859,146 |
| Events in quadrant C | 3,642,074 | 836,776 |
| Events in quadrant D | 5,108,196 | 757,602 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30716 | 4 |
| B | 0 | 17238 | 1 |
| C | 0 | 16711 | 1 |
| D | 0 | 20687 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7933 | 464 | 5.848985% |
| B | 7934 | 216 | 2.722460% |
| C | 7934 | 36 | 0.453743% |
| D | 7934 | 210 | 2.646836% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7933 | 7933 | 12 | 12 | 0.15% | 0.15% |  |
| B | 7934 | 7934 | 11 | 11 | 0.14% | 0.14% |  |
| C | 7934 | 7934 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7934 | 7934 | 156 | 156 | 1.97% | 1.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4471475 | 23034.47 | 924 | 901 | 194.1 |
| A | 9 | 191 | 276571 | 1420.38 | 924 | 901 | 194.1 |
| A | 14 | 248 | 34281 | 171.99 | 924 | 901 | 194.1 |
| B | 0 | 200 | 144432 | 774.16 | 928 | 898 | 185.4 |
| B | 4 | 21 | 63119 | 335.59 | 928 | 898 | 185.4 |
| B | 0 | 246 | 24643 | 128.07 | 928 | 898 | 185.4 |
| C | 12 | 2 | 44545 | 201.49 | 913 | 914 | 216.5 |
| C | 14 | 254 | 23064 | 102.29 | 913 | 914 | 216.5 |
| C | 6 | 247 | 11250 | 47.73 | 913 | 914 | 216.5 |
| D | 12 | 2 | 490502 | 2105.45 | 915 | 883 | 232.5 |
| D | 2 | 165 | 321708 | 1379.6 | 915 | 883 | 232.5 |
| D | 8 | 176 | 238212 | 1020.56 | 915 | 883 | 232.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
