| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_213T01_9000006344_47740cztM0_level2.fits | modeM0/AS1T05_213T01_9000006344_47740cztM0_level2_quad_clean.evt |
| Size (bytes) | 555,082,560 | 120,841,920 |
| Size | 529.4 MB | 115.2 MB |
| Events in quadrant A | 7,657,286 | 792,821 |
| Events in quadrant B | 4,316,466 | 791,569 |
| Events in quadrant C | 4,195,008 | 788,165 |
| Events in quadrant D | 3,778,798 | 748,642 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28539 | 0 |
| B | 0 | 18337 | 0 |
| C | 0 | 18380 | 0 |
| D | 0 | 16973 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7730 | 350 | 4.527814% |
| B | 7731 | 440 | 5.691372% |
| C | 7731 | 348 | 4.501358% |
| D | 7731 | 101 | 1.306429% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7730 | 7730 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7731 | 7731 | 118 | 118 | 1.53% | 1.53% |  |
| C | 7731 | 7731 | 252 | 252 | 3.26% | 3.26% |  |
| D | 7731 | 7731 | 24 | 24 | 0.31% | 0.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4229520 | 23622.4 | 858 | 839 | 179.0 |
| A | 9 | 191 | 50309 | 276.35 | 858 | 839 | 179.0 |
| A | 9 | 143 | 21416 | 114.95 | 858 | 839 | 179.0 |
| B | 5 | 32 | 405049 | 2428.72 | 844 | 815 | 166.4 |
| B | 5 | 255 | 333834 | 2000.84 | 844 | 815 | 166.4 |
| B | 0 | 200 | 125141 | 746.97 | 844 | 815 | 166.4 |
| C | 14 | 254 | 840883 | 4316.8 | 829 | 832 | 194.6 |
| C | 12 | 2 | 102289 | 521.36 | 829 | 832 | 194.6 |
| C | 0 | 207 | 12060 | 57.7 | 829 | 832 | 194.6 |
| D | 10 | 181 | 138221 | 648.73 | 853 | 824 | 211.8 |
| D | 2 | 165 | 76258 | 356.16 | 853 | 824 | 211.8 |
| D | 2 | 249 | 72373 | 337.82 | 853 | 824 | 211.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
