| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_004T02_9000006348_47768cztM0_level2.fits | modeM0/AS1C09_004T02_9000006348_47768cztM0_level2_quad_clean.evt |
| Size (bytes) | 559,958,400 | 106,090,560 |
| Size | 534.0 MB | 101.2 MB |
| Events in quadrant A | 7,108,716 | 728,678 |
| Events in quadrant B | 4,918,230 | 678,326 |
| Events in quadrant C | 3,484,365 | 705,180 |
| Events in quadrant D | 4,683,383 | 620,833 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26467 | 1 |
| B | 0 | 19213 | 2 |
| C | 0 | 15425 | 1 |
| D | 0 | 18864 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6876 | 239 | 3.475858% |
| B | 6876 | 701 | 10.194881% |
| C | 6876 | 127 | 1.847004% |
| D | 6876 | 540 | 7.853403% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7476 | 6877 | 6 | 6 | 0.08% | 0.09% |  |
| B | 7476 | 6877 | 220 | 220 | 2.94% | 3.20% |  |
| C | 7476 | 6877 | 76 | 76 | 1.02% | 1.11% |  |
| D | 7476 | 6877 | 455 | 455 | 6.09% | 6.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4119246 | 26552.61 | 748 | 732 | 155.1 |
| A | 13 | 248 | 39222 | 248.15 | 748 | 732 | 155.1 |
| A | 9 | 191 | 22605 | 141.02 | 748 | 732 | 155.1 |
| B | 12 | 18 | 846050 | 6208.09 | 701 | 680 | 136.2 |
| B | 0 | 186 | 334479 | 2451.3 | 701 | 680 | 136.2 |
| B | 5 | 32 | 244652 | 1791.64 | 701 | 680 | 136.2 |
| C | 12 | 2 | 550226 | 3213.88 | 728 | 730 | 171.0 |
| C | 14 | 254 | 72632 | 420.54 | 728 | 730 | 171.0 |
| C | 12 | 249 | 7744 | 41.02 | 728 | 730 | 171.0 |
| D | 2 | 165 | 1185732 | 6810.74 | 697 | 674 | 174.0 |
| D | 12 | 233 | 287945 | 1651.0 | 697 | 674 | 174.0 |
| D | 7 | 67 | 166939 | 955.55 | 697 | 674 | 174.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
