| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_081T01_9000006354_47824cztM0_level2.fits | modeM0/AS1A13_081T01_9000006354_47824cztM0_level2_quad_clean.evt |
| Size (bytes) | 671,474,880 | 84,098,880 |
| Size | 640.4 MB | 80.2 MB |
| Events in quadrant A | 5,949,458 | 647,155 |
| Events in quadrant B | 2,941,807 | 674,513 |
| Events in quadrant C | 2,783,260 | 632,344 |
| Events in quadrant D | 12,714,684 | 172,949 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22075 | 3 |
| B | 0 | 13006 | 1 |
| C | 0 | 12985 | 1 |
| D | 0 | 41850 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6007 | 205 | 3.412685% |
| B | 6007 | 104 | 1.731313% |
| C | 6006 | 116 | 1.931402% |
| D | 6008 | 4454 | 74.134487% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7117 | 6007 | 9 | 9 | 0.13% | 0.15% |  |
| B | 7117 | 6007 | 11 | 11 | 0.15% | 0.18% |  |
| C | 7117 | 6008 | 61 | 61 | 0.86% | 1.02% |  |
| D | 7118 | 6008 | 4267 | 4267 | 59.95% | 71.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3370974 | 25127.33 | 653 | 639 | 134.1 |
| A | 13 | 248 | 34666 | 253.69 | 653 | 639 | 134.1 |
| A | 0 | 31 | 17978 | 129.27 | 653 | 639 | 134.1 |
| B | 0 | 200 | 275670 | 2173.29 | 652 | 630 | 126.6 |
| B | 12 | 3 | 32770 | 253.96 | 652 | 630 | 126.6 |
| B | 12 | 111 | 15932 | 120.91 | 652 | 630 | 126.6 |
| C | 12 | 2 | 272266 | 1845.46 | 633 | 637 | 147.2 |
| C | 14 | 254 | 29122 | 193.53 | 633 | 637 | 147.2 |
| C | 12 | 250 | 10543 | 67.3 | 633 | 637 | 147.2 |
| D | 12 | 33 | 10586319 | 112519.81 | 372 | 359 | 94.1 |
| D | 12 | 2 | 348222 | 3697.49 | 372 | 359 | 94.1 |
| D | 12 | 32 | 153733 | 1630.24 | 372 | 359 | 94.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
