| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_038T16_9000006364_47860cztM0_level2.fits | modeM0/AS1A09_038T16_9000006364_47860cztM0_level2_quad_clean.evt |
| Size (bytes) | 280,860,480 | 49,728,960 |
| Size | 267.8 MB | 47.4 MB |
| Events in quadrant A | 3,164,995 | 329,265 |
| Events in quadrant B | 1,497,069 | 349,899 |
| Events in quadrant C | 1,544,711 | 343,360 |
| Events in quadrant D | 3,936,936 | 253,527 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 66 | 0 |
| B | 0 | 66 | 0 |
| C | 0 | 66 | 0 |
| D | 0 | 66 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11446 | 2 |
| B | 0 | 6731 | 1 |
| C | 0 | 6817 | 1 |
| D | 0 | 13983 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3236 | 203 | 6.273177% |
| B | 3236 | 102 | 3.152040% |
| C | 3236 | 42 | 1.297899% |
| D | 3236 | 713 | 22.033375% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3571 | 3237 | 2 | 2 | 0.06% | 0.06% |  |
| B | 3571 | 3237 | 0 | 0 | 0.00% | 0.00% |  |
| C | 3571 | 3237 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3571 | 3237 | 553 | 553 | 15.49% | 17.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1725258 | 22090.27 | 367 | 358 | 78.1 |
| A | 13 | 248 | 18542 | 232.88 | 367 | 358 | 78.1 |
| A | 3 | 137 | 4400 | 51.76 | 367 | 358 | 78.1 |
| B | 12 | 0 | 11383 | 146.47 | 370 | 357 | 75.3 |
| B | 12 | 111 | 9572 | 122.42 | 370 | 357 | 75.3 |
| B | 11 | 111 | 8909 | 113.61 | 370 | 357 | 75.3 |
| C | 9 | 237 | 44383 | 497.46 | 373 | 373 | 88.5 |
| C | 4 | 254 | 29948 | 334.29 | 373 | 373 | 88.5 |
| C | 12 | 250 | 2829 | 27.76 | 373 | 373 | 88.5 |
| D | 2 | 37 | 1453579 | 16568.78 | 345 | 334 | 87.7 |
| D | 2 | 165 | 827811 | 9434.26 | 345 | 334 | 87.7 |
| D | 2 | 249 | 181321 | 2063.47 | 345 | 334 | 87.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
