| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_053T01_9000006370_47882cztM0_level2.fits | modeM0/AS1A13_053T01_9000006370_47882cztM0_level2_quad_clean.evt |
| Size (bytes) | 455,633,280 | 109,558,080 |
| Size | 434.5 MB | 104.5 MB |
| Events in quadrant A | 6,711,817 | 705,641 |
| Events in quadrant B | 2,954,078 | 758,735 |
| Events in quadrant C | 2,946,619 | 737,729 |
| Events in quadrant D | 3,749,592 | 662,544 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24568 | 10 |
| B | 0 | 13372 | 2 |
| C | 0 | 13411 | 3 |
| D | 0 | 15856 | 8 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6491 | 267 | 4.113388% |
| B | 6493 | 42 | 0.646850% |
| C | 6492 | 27 | 0.415896% |
| D | 6488 | 146 | 2.250308% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7633 | 6494 | 55 | 55 | 0.72% | 0.85% |  |
| B | 7633 | 6494 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7633 | 6494 | 3 | 3 | 0.04% | 0.05% |  |
| D | 7632 | 6491 | 144 | 144 | 1.89% | 2.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3874849 | 25826.13 | 720 | 702 | 150.0 |
| A | 13 | 248 | 52570 | 345.76 | 720 | 702 | 150.0 |
| A | 7 | 3 | 10372 | 64.46 | 720 | 702 | 150.0 |
| B | 12 | 3 | 21909 | 148.36 | 729 | 707 | 142.9 |
| B | 0 | 183 | 21373 | 144.61 | 729 | 707 | 142.9 |
| B | 12 | 111 | 18105 | 121.74 | 729 | 707 | 142.9 |
| C | 14 | 254 | 57207 | 327.41 | 737 | 741 | 172.5 |
| C | 12 | 2 | 6276 | 32.09 | 737 | 741 | 172.5 |
| C | 3 | 160 | 6123 | 31.2 | 737 | 741 | 172.5 |
| D | 2 | 165 | 658121 | 3687.05 | 724 | 703 | 178.3 |
| D | 12 | 233 | 160042 | 893.63 | 724 | 703 | 178.3 |
| D | 7 | 96 | 55241 | 305.87 | 724 | 703 | 178.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
