| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_053T01_9000006370_47897cztM0_level2.fits | modeM0/AS1A13_053T01_9000006370_47897cztM0_level2_quad_clean.evt |
| Size (bytes) | 494,657,280 | 95,883,840 |
| Size | 471.7 MB | 91.4 MB |
| Events in quadrant A | 6,107,533 | 649,572 |
| Events in quadrant B | 2,756,425 | 683,014 |
| Events in quadrant C | 2,644,926 | 664,042 |
| Events in quadrant D | 6,333,293 | 485,566 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22536 | 1 |
| B | 0 | 12564 | 1 |
| C | 0 | 12339 | 1 |
| D | 0 | 23237 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6031 | 175 | 2.901675% |
| B | 6032 | 57 | 0.944960% |
| C | 6032 | 24 | 0.397878% |
| D | 6032 | 1314 | 21.783820% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7136 | 6032 | 48 | 48 | 0.67% | 0.80% |  |
| B | 7137 | 6033 | 18 | 18 | 0.25% | 0.30% |  |
| C | 7137 | 6033 | 7 | 7 | 0.10% | 0.12% |  |
| D | 7137 | 6033 | 1122 | 1122 | 15.72% | 18.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3453341 | 24970.59 | 658 | 642 | 138.3 |
| A | 7 | 3 | 106565 | 766.06 | 658 | 642 | 138.3 |
| A | 3 | 137 | 7483 | 49.48 | 658 | 642 | 138.3 |
| B | 5 | 255 | 96371 | 735.83 | 663 | 641 | 130.1 |
| B | 12 | 111 | 16254 | 120.01 | 663 | 641 | 130.1 |
| B | 11 | 111 | 15140 | 111.45 | 663 | 641 | 130.1 |
| C | 12 | 2 | 25182 | 155.37 | 668 | 670 | 157.8 |
| C | 1 | 3 | 4539 | 24.52 | 668 | 670 | 157.8 |
| C | 13 | 61 | 4379 | 23.51 | 668 | 670 | 157.8 |
| D | 12 | 2 | 2222604 | 15077.05 | 595 | 576 | 147.4 |
| D | 2 | 37 | 1289417 | 8745.13 | 595 | 576 | 147.4 |
| D | 2 | 249 | 293102 | 1984.87 | 595 | 576 | 147.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
