| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_062T02_9000006384_47998cztM0_level2.fits | modeM0/AS1A13_062T02_9000006384_47998cztM0_level2_quad_clean.evt |
| Size (bytes) | 463,947,840 | 108,699,840 |
| Size | 442.5 MB | 103.7 MB |
| Events in quadrant A | 6,837,970 | 703,059 |
| Events in quadrant B | 3,105,293 | 762,171 |
| Events in quadrant C | 3,455,431 | 719,010 |
| Events in quadrant D | 3,270,354 | 653,271 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24536 | 2 |
| B | 0 | 13727 | 3 |
| C | 0 | 14797 | 2 |
| D | 0 | 14452 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6502 | 398 | 6.121193% |
| B | 6501 | 89 | 1.369020% |
| C | 6501 | 161 | 2.476542% |
| D | 6501 | 119 | 1.830488% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7642 | 6504 | 87 | 87 | 1.14% | 1.34% |  |
| B | 7641 | 6503 | 10 | 10 | 0.13% | 0.15% |  |
| C | 7641 | 6503 | 97 | 97 | 1.27% | 1.49% |  |
| D | 7641 | 6503 | 72 | 72 | 0.94% | 1.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3964998 | 25967.8 | 732 | 716 | 152.7 |
| A | 0 | 31 | 27576 | 175.94 | 732 | 716 | 152.7 |
| A | 13 | 254 | 9116 | 55.02 | 732 | 716 | 152.7 |
| B | 5 | 32 | 37361 | 249.33 | 748 | 725 | 146.9 |
| B | 0 | 198 | 32055 | 213.22 | 748 | 725 | 146.9 |
| B | 4 | 21 | 26686 | 176.68 | 748 | 725 | 146.9 |
| C | 14 | 254 | 449233 | 2579.86 | 736 | 740 | 173.8 |
| C | 12 | 2 | 103993 | 593.94 | 736 | 740 | 173.8 |
| C | 14 | 67 | 12955 | 70.26 | 736 | 740 | 173.8 |
| D | 2 | 249 | 155536 | 852.5 | 731 | 710 | 181.6 |
| D | 2 | 165 | 104323 | 570.51 | 731 | 710 | 181.6 |
| D | 11 | 224 | 98013 | 535.77 | 731 | 710 | 181.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
