| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_218T01_9000006386_48014cztM0_level2.fits | modeM0/AS1T05_218T01_9000006386_48014cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,282,334,400 | 263,992,320 |
| Size | 1.2 GB | 251.8 MB |
| Events in quadrant A | 19,726,222 | 1,573,807 |
| Events in quadrant B | 7,880,490 | 1,881,506 |
| Events in quadrant C | 7,839,362 | 1,772,851 |
| Events in quadrant D | 10,722,865 | 1,605,625 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 342 | 0 |
| B | 0 | 342 | 0 |
| C | 0 | 342 | 0 |
| D | 0 | 342 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 70144 | 3 |
| B | 0 | 35358 | 3 |
| C | 0 | 35753 | 3 |
| D | 0 | 44214 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 31 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 16814 | 2124 | 12.632330% |
| B | 16815 | 153 | 0.909902% |
| C | 16815 | 124 | 0.737437% |
| D | 16815 | 233 | 1.385668% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19944 | 16817 | 1604 | 1604 | 8.04% | 9.54% |  |
| B | 19945 | 16818 | 12 | 12 | 0.06% | 0.07% |  |
| C | 19945 | 16818 | 48 | 48 | 0.24% | 0.29% |  |
| D | 19945 | 16818 | 159 | 159 | 0.80% | 0.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 9304212 | 25506.55 | 1758 | 1721 | 364.7 |
| A | 0 | 31 | 3533626 | 9684.15 | 1758 | 1721 | 364.7 |
| A | 13 | 248 | 54502 | 144.72 | 1758 | 1721 | 364.7 |
| B | 0 | 200 | 211569 | 572.13 | 1870 | 1811 | 366.6 |
| B | 0 | 198 | 55333 | 145.99 | 1870 | 1811 | 366.6 |
| B | 7 | 221 | 54867 | 144.71 | 1870 | 1811 | 366.6 |
| C | 14 | 254 | 286532 | 660.16 | 1837 | 1845 | 431.2 |
| C | 12 | 2 | 263258 | 606.19 | 1837 | 1845 | 431.2 |
| C | 14 | 67 | 57152 | 128.25 | 1837 | 1845 | 431.2 |
| D | 10 | 204 | 2387591 | 5292.54 | 1816 | 1762 | 450.8 |
| D | 2 | 249 | 504620 | 1115.5 | 1816 | 1762 | 450.8 |
| D | 12 | 2 | 197143 | 433.42 | 1816 | 1762 | 450.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
