| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T05_9000006392_48053cztM0_level2.fits | modeM0/AS1A13_037T05_9000006392_48053cztM0_level2_quad_clean.evt |
| Size (bytes) | 554,811,840 | 107,038,080 |
| Size | 529.1 MB | 102.1 MB |
| Events in quadrant A | 7,377,617 | 711,578 |
| Events in quadrant B | 3,560,589 | 747,389 |
| Events in quadrant C | 3,308,618 | 711,087 |
| Events in quadrant D | 5,775,160 | 606,847 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26506 | 2 |
| B | 0 | 15162 | 4 |
| C | 0 | 14693 | 2 |
| D | 0 | 21940 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6653 | 387 | 5.816925% |
| B | 6652 | 163 | 2.450391% |
| C | 6652 | 104 | 1.563440% |
| D | 6652 | 567 | 8.523752% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7743 | 6654 | 91 | 91 | 1.18% | 1.37% |  |
| B | 7742 | 6653 | 55 | 55 | 0.71% | 0.83% |  |
| C | 7742 | 6653 | 65 | 65 | 0.84% | 0.98% |  |
| D | 7742 | 6653 | 461 | 461 | 5.95% | 6.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4450485 | 28382.41 | 746 | 730 | 156.8 |
| A | 0 | 243 | 20652 | 127.07 | 746 | 730 | 156.8 |
| A | 13 | 254 | 11050 | 65.83 | 746 | 730 | 156.8 |
| B | 4 | 171 | 138753 | 919.24 | 751 | 729 | 150.2 |
| B | 7 | 221 | 135567 | 898.02 | 751 | 729 | 150.2 |
| B | 0 | 200 | 114968 | 760.83 | 751 | 729 | 150.2 |
| C | 12 | 2 | 240998 | 1401.45 | 726 | 731 | 171.4 |
| C | 14 | 254 | 111045 | 643.45 | 726 | 731 | 171.4 |
| C | 0 | 207 | 71588 | 413.3 | 726 | 731 | 171.4 |
| D | 2 | 165 | 1548382 | 8574.17 | 710 | 687 | 180.5 |
| D | 2 | 249 | 478745 | 2648.42 | 710 | 687 | 180.5 |
| D | 7 | 67 | 381140 | 2107.69 | 710 | 687 | 180.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
