| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_009T01_9000006406_48155cztM0_level2.fits | modeM0/AS1C09_009T01_9000006406_48155cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,551,956,480 | 515,070,720 |
| Size | 2.4 GB | 491.2 MB |
| Events in quadrant A | 42,488,009 | 4,446,337 |
| Events in quadrant B | 7,057,676 | 320 |
| Events in quadrant C | 19,144,647 | 4,435,195 |
| Events in quadrant D | 22,669,916 | 3,992,137 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 808 | 0 |
| B | 0 | 808 | 0 |
| C | 0 | 808 | 0 |
| D | 0 | 808 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154264 | 6 |
| B | 0 | 42945 | 6 |
| C | 0 | 85002 | 6 |
| D | 0 | 95482 | 6 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 43 | 0 |
| B | 0 | 43 | 0 |
| C | 0 | 43 | 0 |
| D | 0 | 43 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 39600 | 1602 | 4.045455% |
| B | 39601 | 39599 | 99.994950% |
| C | 39601 | 565 | 1.426732% |
| D | 39601 | 1077 | 2.719628% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 44105 | 39607 | 164 | 164 | 0.37% | 0.41% |  |
| B | 44105 | 39459 | 14 | 14 | 0.03% | 0.04% |  |
| C | 44106 | 39607 | 202 | 202 | 0.46% | 0.51% |  |
| D | 44106 | 39607 | 534 | 534 | 1.21% | 1.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 24253267 | 25478.73 | 4555 | 4466 | 951.7 |
| A | 13 | 248 | 270991 | 280.04 | 4555 | 4466 | 951.7 |
| A | 0 | 31 | 143551 | 146.14 | 4555 | 4466 | 951.7 |
| B | 2 | 177 | 5455710 | 90895.53 | 287 | 280 | 60.0 |
| B | 4 | 171 | 240001 | 3994.11 | 287 | 280 | 60.0 |
| B | 4 | 21 | 148102 | 2462.93 | 287 | 280 | 60.0 |
| C | 14 | 254 | 707758 | 662.92 | 4487 | 4529 | 1060.8 |
| C | 12 | 2 | 660038 | 617.93 | 4487 | 4529 | 1060.8 |
| C | 0 | 207 | 120319 | 109.15 | 4487 | 4529 | 1060.8 |
| D | 2 | 165 | 1295607 | 1138.66 | 4479 | 4344 | 1134.0 |
| D | 12 | 233 | 1266255 | 1112.78 | 4479 | 4344 | 1134.0 |
| D | 12 | 2 | 1016447 | 892.49 | 4479 | 4344 | 1134.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
