| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_029T01_9000006422_48254cztM0_level2.fits | modeM0/AS1A13_029T01_9000006422_48254cztM0_level2_quad_clean.evt |
| Size (bytes) | 962,352,000 | 213,857,280 |
| Size | 917.8 MB | 204.0 MB |
| Events in quadrant A | 14,042,333 | 1,376,244 |
| Events in quadrant B | 6,964,976 | 1,470,721 |
| Events in quadrant C | 6,243,274 | 1,412,454 |
| Events in quadrant D | 7,326,383 | 1,280,537 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 51878 | 3 |
| B | 0 | 29819 | 3 |
| C | 0 | 28384 | 3 |
| D | 0 | 31218 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 278 | 0 |
| B | 0 | 278 | 0 |
| C | 0 | 278 | 0 |
| D | 0 | 278 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 13531 | 496 | 3.665657% |
| B | 13532 | 236 | 1.744014% |
| C | 13531 | 158 | 1.167689% |
| D | 13531 | 290 | 2.143227% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 15981 | 13531 | 64 | 64 | 0.40% | 0.47% |  |
| B | 15982 | 13532 | 58 | 58 | 0.36% | 0.43% |  |
| C | 15981 | 13531 | 61 | 61 | 0.38% | 0.45% |  |
| D | 15981 | 13531 | 171 | 171 | 1.07% | 1.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 7835372 | 24834.73 | 1512 | 1479 | 315.4 |
| A | 13 | 248 | 198863 | 625.74 | 1512 | 1479 | 315.4 |
| A | 7 | 3 | 150842 | 473.51 | 1512 | 1479 | 315.4 |
| B | 4 | 21 | 304525 | 1005.37 | 1519 | 1470 | 301.4 |
| B | 0 | 200 | 194449 | 640.2 | 1519 | 1470 | 301.4 |
| B | 0 | 186 | 170755 | 561.59 | 1519 | 1470 | 301.4 |
| C | 12 | 2 | 352629 | 992.7 | 1499 | 1506 | 353.7 |
| C | 12 | 249 | 13792 | 34.74 | 1499 | 1506 | 353.7 |
| C | 3 | 233 | 13116 | 32.82 | 1499 | 1506 | 353.7 |
| D | 12 | 1 | 810059 | 2158.7 | 1500 | 1457 | 374.6 |
| D | 2 | 120 | 375810 | 999.4 | 1500 | 1457 | 374.6 |
| D | 2 | 249 | 114761 | 302.48 | 1500 | 1457 | 374.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
