| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_029T01_9000006422_48256cztM0_level2.fits | modeM0/AS1A13_029T01_9000006422_48256cztM0_level2_quad_clean.evt |
| Size (bytes) | 741,781,440 | 172,319,040 |
| Size | 707.4 MB | 164.3 MB |
| Events in quadrant A | 11,004,711 | 1,133,460 |
| Events in quadrant B | 5,456,054 | 1,175,923 |
| Events in quadrant C | 4,664,923 | 1,138,667 |
| Events in quadrant D | 5,513,522 | 1,036,191 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 41033 | 2 |
| B | 0 | 23205 | 2 |
| C | 0 | 21534 | 3 |
| D | 0 | 23626 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 218 | 0 |
| B | 0 | 218 | 0 |
| C | 0 | 218 | 0 |
| D | 0 | 218 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10581 | 377 | 3.562990% |
| B | 10582 | 200 | 1.890002% |
| C | 10581 | 77 | 0.727719% |
| D | 10581 | 158 | 1.493243% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 12636 | 10581 | 82 | 82 | 0.65% | 0.77% |  |
| B | 12637 | 10582 | 48 | 48 | 0.38% | 0.45% |  |
| C | 12636 | 10581 | 0 | 0 | 0.00% | 0.00% |  |
| D | 12636 | 10581 | 46 | 46 | 0.36% | 0.43% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 6164725 | 24825.55 | 1196 | 1167 | 248.3 |
| A | 13 | 248 | 141436 | 564.97 | 1196 | 1167 | 248.3 |
| A | 3 | 14 | 50891 | 200.28 | 1196 | 1167 | 248.3 |
| B | 4 | 21 | 225477 | 953.72 | 1197 | 1156 | 235.2 |
| B | 5 | 255 | 188521 | 796.6 | 1197 | 1156 | 235.2 |
| B | 0 | 200 | 96956 | 407.3 | 1197 | 1156 | 235.2 |
| C | 12 | 249 | 15821 | 52.68 | 1183 | 1188 | 277.8 |
| C | 12 | 2 | 14888 | 49.32 | 1183 | 1188 | 277.8 |
| C | 3 | 233 | 14575 | 48.19 | 1183 | 1188 | 277.8 |
| D | 12 | 1 | 350137 | 1178.15 | 1189 | 1154 | 296.2 |
| D | 2 | 120 | 192314 | 645.35 | 1189 | 1154 | 296.2 |
| D | 2 | 249 | 109275 | 365.01 | 1189 | 1154 | 296.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
