| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_029T01_9000006422_48264cztM0_level2.fits | modeM0/AS1A13_029T01_9000006422_48264cztM0_level2_quad_clean.evt |
| Size (bytes) | 628,911,360 | 137,096,640 |
| Size | 599.8 MB | 130.7 MB |
| Events in quadrant A | 8,583,771 | 911,035 |
| Events in quadrant B | 4,441,633 | 936,639 |
| Events in quadrant C | 3,874,189 | 896,565 |
| Events in quadrant D | 5,717,285 | 811,438 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31141 | 0 |
| B | 0 | 19119 | 0 |
| C | 0 | 17792 | 0 |
| D | 0 | 23091 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8568 | 202 | 2.357610% |
| B | 8569 | 106 | 1.237017% |
| C | 8569 | 18 | 0.210060% |
| D | 8569 | 176 | 2.053915% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8567 | 8567 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8568 | 8568 | 42 | 42 | 0.49% | 0.49% |  |
| C | 8569 | 8569 | 7 | 7 | 0.08% | 0.08% |  |
| D | 8568 | 8568 | 165 | 165 | 1.93% | 1.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4779908 | 23374.94 | 972 | 948 | 204.4 |
| A | 13 | 248 | 30442 | 144.26 | 972 | 948 | 204.4 |
| A | 13 | 254 | 17929 | 83.06 | 972 | 948 | 204.4 |
| B | 5 | 255 | 269542 | 1389.18 | 974 | 942 | 193.4 |
| B | 4 | 21 | 137526 | 706.4 | 974 | 942 | 193.4 |
| B | 12 | 18 | 46174 | 233.94 | 974 | 942 | 193.4 |
| C | 14 | 254 | 112463 | 490.65 | 960 | 962 | 227.3 |
| C | 0 | 207 | 7654 | 29.45 | 960 | 962 | 227.3 |
| C | 13 | 61 | 6449 | 24.15 | 960 | 962 | 227.3 |
| D | 2 | 165 | 913863 | 3799.27 | 949 | 917 | 240.3 |
| D | 12 | 3 | 630066 | 2618.24 | 949 | 917 | 240.3 |
| D | 2 | 249 | 280651 | 1164.13 | 949 | 917 | 240.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
