| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_029T01_9000006422_48276cztM0_level2.fits | modeM0/AS1A13_029T01_9000006422_48276cztM0_level2_quad_clean.evt |
| Size (bytes) | 557,328,960 | 121,060,800 |
| Size | 531.5 MB | 115.5 MB |
| Events in quadrant A | 8,100,178 | 767,277 |
| Events in quadrant B | 4,048,078 | 824,105 |
| Events in quadrant C | 3,698,663 | 809,994 |
| Events in quadrant D | 4,189,817 | 731,959 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29145 | 2 |
| B | 0 | 17147 | 2 |
| C | 0 | 16535 | 3 |
| D | 0 | 17868 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7654 | 690 | 9.014894% |
| B | 7655 | 361 | 4.715872% |
| C | 7654 | 141 | 1.842174% |
| D | 7654 | 188 | 2.456232% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8724 | 7657 | 7 | 7 | 0.08% | 0.09% |  |
| B | 8725 | 7658 | 25 | 25 | 0.29% | 0.33% |  |
| C | 8724 | 7657 | 6 | 6 | 0.07% | 0.08% |  |
| D | 8724 | 7657 | 12 | 12 | 0.14% | 0.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4619469 | 24555.49 | 893 | 873 | 188.1 |
| A | 13 | 254 | 15681 | 78.73 | 893 | 873 | 188.1 |
| A | 0 | 243 | 12653 | 62.63 | 893 | 873 | 188.1 |
| B | 4 | 21 | 254074 | 1389.7 | 906 | 876 | 182.2 |
| B | 5 | 255 | 52546 | 283.6 | 906 | 876 | 182.2 |
| B | 0 | 200 | 41446 | 222.67 | 906 | 876 | 182.2 |
| C | 0 | 207 | 69027 | 319.79 | 895 | 898 | 213.0 |
| C | 12 | 2 | 64404 | 298.09 | 895 | 898 | 213.0 |
| C | 14 | 254 | 60224 | 278.47 | 895 | 898 | 213.0 |
| D | 7 | 67 | 294386 | 1264.24 | 898 | 869 | 232.2 |
| D | 2 | 165 | 138072 | 590.96 | 898 | 869 | 232.2 |
| D | 12 | 3 | 88719 | 378.39 | 898 | 869 | 232.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
