| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_029T01_9000006422_48289cztM0_level2.fits | modeM0/AS1A13_029T01_9000006422_48289cztM0_level2_quad_clean.evt |
| Size (bytes) | 507,067,200 | 108,529,920 |
| Size | 483.6 MB | 103.5 MB |
| Events in quadrant A | 7,186,180 | 709,277 |
| Events in quadrant B | 3,519,218 | 748,544 |
| Events in quadrant C | 3,376,033 | 719,897 |
| Events in quadrant D | 4,174,422 | 646,159 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26128 | 1 |
| B | 0 | 14757 | 1 |
| C | 0 | 14612 | 1 |
| D | 0 | 16938 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6626 | 418 | 6.308482% |
| B | 6626 | 204 | 3.078781% |
| C | 6626 | 149 | 2.248717% |
| D | 6626 | 316 | 4.769091% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7561 | 6627 | 24 | 24 | 0.32% | 0.36% |  |
| B | 7561 | 6627 | 8 | 8 | 0.11% | 0.12% |  |
| C | 7561 | 6627 | 35 | 35 | 0.46% | 0.53% |  |
| D | 7561 | 6627 | 131 | 131 | 1.73% | 1.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4102320 | 25258.23 | 777 | 760 | 162.4 |
| A | 13 | 248 | 46217 | 279.93 | 777 | 760 | 162.4 |
| A | 0 | 247 | 17012 | 100.08 | 777 | 760 | 162.4 |
| B | 0 | 200 | 235032 | 1500.3 | 785 | 761 | 156.1 |
| B | 4 | 21 | 83314 | 528.68 | 785 | 761 | 156.1 |
| B | 5 | 255 | 40987 | 257.61 | 785 | 761 | 156.1 |
| C | 0 | 207 | 149323 | 815.98 | 771 | 776 | 182.0 |
| C | 14 | 254 | 127796 | 697.73 | 771 | 776 | 182.0 |
| C | 2 | 207 | 34462 | 185.04 | 771 | 776 | 182.0 |
| D | 2 | 165 | 530013 | 2728.03 | 769 | 746 | 194.0 |
| D | 2 | 249 | 425841 | 2191.09 | 769 | 746 | 194.0 |
| D | 7 | 67 | 94878 | 485.19 | 769 | 746 | 194.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
