| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T05_9000006424_48343cztM0_level2.fits | modeM0/AS1A13_037T05_9000006424_48343cztM0_level2_quad_clean.evt |
| Size (bytes) | 456,733,440 | 104,613,120 |
| Size | 435.6 MB | 99.8 MB |
| Events in quadrant A | 6,696,961 | 691,675 |
| Events in quadrant B | 3,356,465 | 725,448 |
| Events in quadrant C | 2,793,843 | 692,394 |
| Events in quadrant D | 3,567,467 | 615,933 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24885 | 1 |
| B | 0 | 14261 | 1 |
| C | 0 | 12956 | 1 |
| D | 0 | 15097 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6337 | 210 | 3.313871% |
| B | 6337 | 128 | 2.019883% |
| C | 6338 | 37 | 0.583780% |
| D | 6338 | 215 | 3.392237% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7447 | 6337 | 33 | 33 | 0.44% | 0.52% |  |
| B | 7447 | 6338 | 53 | 53 | 0.71% | 0.84% |  |
| C | 7448 | 6339 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7448 | 6339 | 173 | 173 | 2.32% | 2.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3866778 | 26424.34 | 706 | 695 | 146.3 |
| A | 13 | 248 | 93365 | 633.39 | 706 | 695 | 146.3 |
| A | 13 | 254 | 12642 | 81.66 | 706 | 695 | 146.3 |
| B | 4 | 21 | 419359 | 2993.74 | 708 | 685 | 139.8 |
| B | 0 | 200 | 77115 | 546.51 | 708 | 685 | 139.8 |
| B | 12 | 111 | 17443 | 119.83 | 708 | 685 | 139.8 |
| C | 12 | 2 | 22707 | 132.84 | 704 | 706 | 165.6 |
| C | 12 | 249 | 22290 | 130.32 | 704 | 706 | 165.6 |
| C | 13 | 61 | 4558 | 23.26 | 704 | 706 | 165.6 |
| D | 2 | 165 | 339953 | 1929.85 | 694 | 671 | 175.8 |
| D | 2 | 249 | 317292 | 1800.96 | 694 | 671 | 175.8 |
| D | 12 | 2 | 146750 | 830.9 | 694 | 671 | 175.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
