| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_029T01_9000006426_48408cztM0_level2.fits | modeM0/AS1A13_029T01_9000006426_48408cztM0_level2_quad_clean.evt |
| Size (bytes) | 669,329,280 | 123,721,920 |
| Size | 638.3 MB | 118.0 MB |
| Events in quadrant A | 8,472,412 | 833,287 |
| Events in quadrant B | 5,428,668 | 834,224 |
| Events in quadrant C | 3,639,319 | 840,328 |
| Events in quadrant D | 6,609,429 | 675,775 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30922 | 0 |
| B | 0 | 21861 | 0 |
| C | 0 | 17011 | 0 |
| D | 0 | 25476 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8089 | 358 | 4.425763% |
| B | 8090 | 537 | 6.637824% |
| C | 8090 | 22 | 0.271941% |
| D | 8090 | 1080 | 13.349815% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8089 | 8089 | 61 | 61 | 0.75% | 0.75% |  |
| B | 8090 | 8090 | 198 | 198 | 2.45% | 2.45% |  |
| C | 8090 | 8090 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8090 | 8090 | 815 | 815 | 10.07% | 10.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4632045 | 24302.96 | 909 | 889 | 190.6 |
| A | 13 | 248 | 319394 | 1671.42 | 909 | 889 | 190.6 |
| A | 13 | 254 | 16713 | 83.04 | 909 | 889 | 190.6 |
| B | 12 | 16 | 1747290 | 9806.32 | 893 | 864 | 178.1 |
| B | 0 | 183 | 40307 | 221.48 | 893 | 864 | 178.1 |
| B | 0 | 198 | 39359 | 216.15 | 893 | 864 | 178.1 |
| C | 15 | 208 | 116633 | 544.32 | 896 | 898 | 212.6 |
| C | 14 | 254 | 18374 | 82.19 | 896 | 898 | 212.6 |
| C | 9 | 237 | 8689 | 36.64 | 896 | 898 | 212.6 |
| D | 12 | 2 | 1546715 | 7182.68 | 848 | 822 | 215.2 |
| D | 5 | 222 | 969102 | 4498.92 | 848 | 822 | 215.2 |
| D | 2 | 249 | 627813 | 2913.19 | 848 | 822 | 215.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
