| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_029T01_9000006426_48413cztM0_level2.fits | modeM0/AS1A13_029T01_9000006426_48413cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,285,824,960 | 261,025,920 |
| Size | 1.2 GB | 248.9 MB |
| Events in quadrant A | 17,802,721 | 1,732,671 |
| Events in quadrant B | 12,953,981 | 1,599,675 |
| Events in quadrant C | 7,712,591 | 1,765,806 |
| Events in quadrant D | 7,783,641 | 1,605,834 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 64488 | 3 |
| B | 0 | 51131 | 3 |
| C | 0 | 36259 | 3 |
| D | 0 | 36557 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 354 | 0 |
| B | 0 | 354 | 0 |
| C | 0 | 354 | 0 |
| D | 0 | 354 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 17386 | 618 | 3.554584% |
| B | 17387 | 2185 | 12.566860% |
| C | 17387 | 85 | 0.488871% |
| D | 17387 | 94 | 0.540634% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19571 | 17389 | 217 | 217 | 1.11% | 1.25% |  |
| B | 19572 | 17390 | 1449 | 1449 | 7.40% | 8.33% |  |
| C | 19572 | 17390 | 37 | 37 | 0.19% | 0.21% |  |
| D | 19572 | 17390 | 52 | 52 | 0.27% | 0.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 10090141 | 26473.36 | 1841 | 1804 | 381.1 |
| A | 13 | 248 | 505094 | 1320.71 | 1841 | 1804 | 381.1 |
| A | 15 | 192 | 66633 | 170.12 | 1841 | 1804 | 381.1 |
| B | 12 | 16 | 5922640 | 17315.64 | 1742 | 1689 | 341.9 |
| B | 8 | 234 | 54774 | 155.24 | 1742 | 1689 | 341.9 |
| B | 12 | 111 | 43999 | 123.73 | 1742 | 1689 | 341.9 |
| C | 15 | 208 | 407304 | 933.87 | 1835 | 1845 | 434.2 |
| C | 12 | 2 | 112060 | 253.85 | 1835 | 1845 | 434.2 |
| C | 1 | 16 | 24720 | 52.69 | 1835 | 1845 | 434.2 |
| D | 2 | 249 | 131038 | 282.44 | 1826 | 1774 | 457.7 |
| D | 5 | 32 | 121209 | 260.96 | 1826 | 1774 | 457.7 |
| D | 2 | 120 | 85745 | 183.47 | 1826 | 1774 | 457.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
