| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_029T01_9000006426_48418cztM0_level2.fits | modeM0/AS1A13_029T01_9000006426_48418cztM0_level2_quad_clean.evt |
| Size (bytes) | 353,534,400 | 85,870,080 |
| Size | 337.2 MB | 81.9 MB |
| Events in quadrant A | 5,425,440 | 532,553 |
| Events in quadrant B | 2,498,741 | 596,904 |
| Events in quadrant C | 2,342,937 | 581,966 |
| Events in quadrant D | 2,416,021 | 526,188 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23608 | 3636 |
| B | 0 | 12253 | 1259 |
| C | 0 | 11933 | 1178 |
| D | 0 | 12242 | 1253 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 16 |
| B | 0 | 120 | 18 |
| C | 0 | 120 | 14 |
| D | 0 | 120 | 16 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4944 | 240 | 4.854369% |
| B | 5224 | 76 | 1.454824% |
| C | 5261 | 13 | 0.247101% |
| D | 5261 | 31 | 0.589242% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7110 | 5348 | 80 | 80 | 1.13% | 1.50% |  |
| B | 7111 | 5529 | 11 | 11 | 0.15% | 0.20% |  |
| C | 7111 | 5556 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7112 | 5569 | 3 | 3 | 0.04% | 0.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2912353 | 24802.08 | 563 | 551 | 117.4 |
| A | 13 | 248 | 325963 | 2771.79 | 563 | 551 | 117.4 |
| A | 13 | 254 | 9625 | 77.29 | 563 | 551 | 117.4 |
| B | 12 | 16 | 118640 | 993.7 | 596 | 579 | 118.8 |
| B | 12 | 111 | 14652 | 118.45 | 596 | 579 | 118.8 |
| B | 11 | 111 | 13882 | 111.97 | 596 | 579 | 118.8 |
| C | 15 | 208 | 15464 | 105.16 | 595 | 597 | 141.4 |
| C | 11 | 16 | 6670 | 42.96 | 595 | 597 | 141.4 |
| C | 13 | 61 | 3944 | 23.67 | 595 | 597 | 141.4 |
| D | 2 | 249 | 24920 | 162.41 | 597 | 579 | 149.9 |
| D | 13 | 171 | 24905 | 162.31 | 597 | 579 | 149.9 |
| D | 2 | 234 | 24245 | 157.9 | 597 | 579 | 149.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
