| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_081T01_9000006428_48478cztM0_level2.fits | modeM0/AS1A13_081T01_9000006428_48478cztM0_level2_quad_clean.evt |
| Size (bytes) | 437,284,800 | 100,523,520 |
| Size | 417.0 MB | 95.9 MB |
| Events in quadrant A | 6,451,341 | 659,856 |
| Events in quadrant B | 2,850,782 | 693,693 |
| Events in quadrant C | 2,672,995 | 657,230 |
| Events in quadrant D | 3,709,398 | 582,615 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24220 | 2 |
| B | 0 | 13361 | 1 |
| C | 0 | 13214 | 1 |
| D | 0 | 15864 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6461 | 279 | 4.318217% |
| B | 6461 | 156 | 2.414487% |
| C | 6462 | 91 | 1.408233% |
| D | 6462 | 341 | 5.277004% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7221 | 6461 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7221 | 6461 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7222 | 6462 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7222 | 6462 | 212 | 212 | 2.94% | 3.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3791930 | 26538.82 | 684 | 670 | 142.9 |
| A | 13 | 254 | 12611 | 83.59 | 684 | 670 | 142.9 |
| A | 10 | 255 | 10732 | 70.43 | 684 | 670 | 142.9 |
| B | 8 | 234 | 53103 | 386.56 | 690 | 669 | 135.6 |
| B | 12 | 16 | 38812 | 281.2 | 690 | 669 | 135.6 |
| B | 0 | 186 | 28788 | 207.3 | 690 | 669 | 135.6 |
| C | 1 | 3 | 15197 | 91.99 | 676 | 677 | 157.8 |
| C | 12 | 2 | 9234 | 54.21 | 676 | 677 | 157.8 |
| C | 12 | 250 | 6665 | 37.94 | 676 | 677 | 157.8 |
| D | 2 | 249 | 603981 | 3649.06 | 665 | 644 | 165.3 |
| D | 7 | 38 | 349712 | 2111.21 | 665 | 644 | 165.3 |
| D | 2 | 165 | 47015 | 280.46 | 665 | 644 | 165.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
