| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006436_48524cztM0_level2.fits | modeM0/AS1A13_037T01_9000006436_48524cztM0_level2_quad_clean.evt |
| Size (bytes) | 505,598,400 | 117,956,160 |
| Size | 482.2 MB | 112.5 MB |
| Events in quadrant A | 7,300,593 | 778,315 |
| Events in quadrant B | 3,354,581 | 809,594 |
| Events in quadrant C | 3,078,437 | 771,392 |
| Events in quadrant D | 4,395,778 | 686,694 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28623 | 1446 |
| B | 0 | 16212 | 680 |
| C | 0 | 15847 | 696 |
| D | 0 | 19622 | 785 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 6 |
| B | 0 | 158 | 6 |
| C | 0 | 158 | 10 |
| D | 0 | 158 | 6 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7519 | 66 | 0.877776% |
| B | 7566 | 25 | 0.330426% |
| C | 7559 | 1 | 0.013229% |
| D | 7570 | 198 | 2.615588% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7690 | 7594 | 5 | 5 | 0.07% | 0.07% |  |
| B | 7795 | 7637 | 7 | 7 | 0.09% | 0.09% |  |
| C | 7719 | 7632 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7682 | 7630 | 157 | 157 | 2.04% | 2.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3963908 | 23417.89 | 798 | 781 | 169.2 |
| A | 12 | 189 | 237423 | 1398.3 | 798 | 781 | 169.2 |
| A | 13 | 254 | 13784 | 76.83 | 798 | 781 | 169.2 |
| B | 12 | 16 | 93916 | 588.34 | 799 | 773 | 158.3 |
| B | 5 | 255 | 67188 | 419.51 | 799 | 773 | 158.3 |
| B | 0 | 183 | 24776 | 151.61 | 799 | 773 | 158.3 |
| C | 3 | 233 | 6267 | 29.6 | 787 | 790 | 185.1 |
| C | 13 | 61 | 5123 | 23.41 | 787 | 790 | 185.1 |
| C | 12 | 250 | 3743 | 15.96 | 787 | 790 | 185.1 |
| D | 2 | 165 | 972946 | 4973.39 | 776 | 752 | 195.5 |
| D | 2 | 249 | 264305 | 1348.24 | 776 | 752 | 195.5 |
| D | 12 | 233 | 106276 | 539.82 | 776 | 752 | 195.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
