| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006436_48561cztM0_level2.fits | modeM0/AS1A13_037T01_9000006436_48561cztM0_level2_quad_clean.evt |
| Size (bytes) | 425,416,320 | 103,772,160 |
| Size | 405.7 MB | 99.0 MB |
| Events in quadrant A | 6,808,238 | 664,882 |
| Events in quadrant B | 2,772,409 | 721,853 |
| Events in quadrant C | 2,656,738 | 690,322 |
| Events in quadrant D | 3,012,186 | 618,026 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24579 | 5 |
| B | 0 | 13086 | 2 |
| C | 0 | 12968 | 2 |
| D | 0 | 14012 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 1 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6408 | 283 | 4.416355% |
| B | 6408 | 24 | 0.374532% |
| C | 6408 | 13 | 0.202871% |
| D | 6408 | 63 | 0.983146% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7548 | 6409 | 151 | 151 | 2.00% | 2.36% |  |
| B | 7548 | 6409 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7548 | 6409 | 3 | 3 | 0.04% | 0.05% |  |
| D | 7548 | 6409 | 50 | 50 | 0.66% | 0.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 4022121 | 28760.41 | 672 | 659 | 139.8 |
| A | 12 | 189 | 98361 | 698.74 | 672 | 659 | 139.8 |
| A | 13 | 248 | 39454 | 277.45 | 672 | 659 | 139.8 |
| B | 5 | 255 | 32241 | 235.44 | 686 | 663 | 134.1 |
| B | 12 | 111 | 17250 | 123.67 | 686 | 663 | 134.1 |
| B | 11 | 111 | 15716 | 112.23 | 686 | 663 | 134.1 |
| C | 12 | 250 | 13195 | 78.84 | 676 | 679 | 158.7 |
| C | 14 | 254 | 6294 | 35.37 | 676 | 679 | 158.7 |
| C | 13 | 61 | 4452 | 23.77 | 676 | 679 | 158.7 |
| D | 2 | 249 | 274852 | 1629.03 | 666 | 646 | 168.3 |
| D | 2 | 165 | 116182 | 686.39 | 666 | 646 | 168.3 |
| D | 2 | 234 | 34563 | 201.5 | 666 | 646 | 168.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
