| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006436_48600cztM0_level2.fits | modeM0/AS1A13_037T01_9000006436_48600cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,501,156,800 | 290,007,360 |
| Size | 1.4 GB | 276.6 MB |
| Events in quadrant A | 19,204,740 | 1,930,971 |
| Events in quadrant B | 16,828,022 | 1,806,670 |
| Events in quadrant C | 8,239,254 | 1,958,814 |
| Events in quadrant D | 9,784,900 | 1,736,141 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 71644 | 2 |
| B | 0 | 63577 | 2 |
| C | 0 | 40078 | 2 |
| D | 0 | 44514 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 396 | 0 |
| B | 0 | 396 | 0 |
| C | 0 | 396 | 0 |
| D | 0 | 396 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19555 | 741 | 3.789312% |
| B | 19555 | 2744 | 14.032217% |
| C | 19556 | 222 | 1.135201% |
| D | 19556 | 590 | 3.016977% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20430 | 19557 | 24 | 24 | 0.12% | 0.12% |  |
| B | 20430 | 19557 | 1777 | 1777 | 8.70% | 9.09% |  |
| C | 20431 | 19558 | 6 | 6 | 0.03% | 0.03% |  |
| D | 20431 | 19558 | 247 | 247 | 1.21% | 1.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 10851468 | 24701.67 | 2107 | 2061 | 439.2 |
| A | 13 | 248 | 185972 | 418.72 | 2107 | 2061 | 439.2 |
| A | 13 | 254 | 36250 | 77.84 | 2107 | 2061 | 439.2 |
| B | 12 | 16 | 8608283 | 21716.49 | 2018 | 1948 | 396.3 |
| B | 0 | 186 | 95590 | 236.29 | 2018 | 1948 | 396.3 |
| B | 12 | 111 | 51694 | 125.52 | 2018 | 1948 | 396.3 |
| C | 12 | 250 | 40907 | 78.61 | 2094 | 2098 | 493.7 |
| C | 12 | 249 | 27219 | 50.88 | 2094 | 2098 | 493.7 |
| C | 13 | 61 | 13907 | 23.92 | 2094 | 2098 | 493.7 |
| D | 2 | 249 | 758001 | 1452.12 | 2069 | 2000 | 520.6 |
| D | 2 | 165 | 532803 | 1019.56 | 2069 | 2000 | 520.6 |
| D | 10 | 199 | 267033 | 509.07 | 2069 | 2000 | 520.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
