| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006436_48710cztM0_level2.fits | modeM0/AS1A13_037T01_9000006436_48710cztM0_level2_quad_clean.evt |
| Size (bytes) | 424,370,880 | 104,682,240 |
| Size | 404.7 MB | 99.8 MB |
| Events in quadrant A | 6,748,517 | 669,000 |
| Events in quadrant B | 2,865,992 | 722,342 |
| Events in quadrant C | 2,783,788 | 695,203 |
| Events in quadrant D | 2,801,750 | 626,539 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24389 | 2 |
| B | 0 | 13464 | 2 |
| C | 0 | 13328 | 2 |
| D | 0 | 13497 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6545 | 280 | 4.278075% |
| B | 6546 | 32 | 0.488848% |
| C | 6546 | 9 | 0.137489% |
| D | 6546 | 11 | 0.168042% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7509 | 6545 | 165 | 165 | 2.20% | 2.52% |  |
| B | 7511 | 6547 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7511 | 6547 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7511 | 6547 | 6 | 6 | 0.08% | 0.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3876341 | 26864.29 | 689 | 672 | 144.3 |
| A | 13 | 248 | 197394 | 1363.58 | 689 | 672 | 144.3 |
| A | 13 | 254 | 12769 | 83.85 | 689 | 672 | 144.3 |
| B | 12 | 16 | 38149 | 268.67 | 707 | 683 | 139.4 |
| B | 12 | 111 | 17971 | 123.97 | 707 | 683 | 139.4 |
| B | 11 | 111 | 16587 | 114.05 | 707 | 683 | 139.4 |
| C | 3 | 233 | 31319 | 185.77 | 698 | 701 | 164.8 |
| C | 14 | 254 | 11347 | 64.59 | 698 | 701 | 164.8 |
| C | 12 | 2 | 8469 | 47.13 | 698 | 701 | 164.8 |
| D | 12 | 238 | 71402 | 411.61 | 687 | 666 | 171.9 |
| D | 2 | 234 | 33745 | 192.49 | 687 | 666 | 171.9 |
| D | 2 | 233 | 30247 | 172.13 | 687 | 666 | 171.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
